Cold Roll Cs 10-30m/Min 165mm Steel Pipe Manufacturing Machine

Certification
China Hebei Tengtian Welded Pipe Equipment Manufacturing Co.,Ltd. certification
China Hebei Tengtian Welded Pipe Equipment Manufacturing Co.,Ltd. certification
Customer Reviews
Thanks for your pipe mill,very good quality and best after-slae service!

—— Mr.Gaber Ibrahim

Dear Amy, Nice day. We have received your mill machine,very good,thanks

—— Eng.Sandeep Sharma

Hi Ms.Amy, Greetings! Thanks for everything when visiting you,very nice factory and good quality machine. Hopefully we can be good patners in future.

—— Ddwin Jakobs

I'm Online Chat Now

Cold Roll Cs 10-30m/Min 165mm Steel Pipe Manufacturing Machine

Cold Roll Cs 10-30m/Min 165mm Steel Pipe Manufacturing Machine
Cold Roll Cs 10-30m/Min 165mm Steel Pipe Manufacturing Machine Cold Roll Cs 10-30m/Min 165mm Steel Pipe Manufacturing Machine

Large Image :  Cold Roll Cs 10-30m/Min 165mm Steel Pipe Manufacturing Machine

Product Details:

Place of Origin: China
Brand Name: Tengtian
Certification: CE / ISO
Model Number: HG325

Payment & Shipping Terms:

Minimum Order Quantity: 1 Set
Price: Negotiable according to different sizes of machine
Packaging Details: Special export packing, and fixed in container
Delivery Time: 2 Months - 4 Months
Payment Terms: T/T, L/C
Supply Ability: 100 Sets/Year
Detailed Product Description
Forming Method: Cold Roll Forming By Rollers Welding Type: High Frequency Welding
Cutting Saw: Cold Saw & Friction Saw Cutting Feature: High Precision; More Stable; High Speed;
Customized: Machine Designing As Per Customer Requirement Welding Speed: 10-30m/min
Raw Material: HRC, CRC, Galvanised Steel Name: Cs Steel Pipe Manufacturing Machine
High Light:

30m/min steel pipe manufacturing machine

,

10m/min steel pipe manufacturing machine

,

165mm Steel Pipe Manufacturing Machine



Model Number

HG325

Place of Origin

Hebei, China (Mainland)

Molding speed

10-30m/min

Pipe diameter

165-325mm

Pipe Thickness

4-12mm

Voltage

380V/220V

Power

1200KW

Certification

ISO9001,CE,BV

Pipe shape

Rectangle,round,square

Material of Pipe

Carbon Steel , Stainless Steel and Galvanized Steel



High frequency straight seam welded pipe production line is the specifications of the steel belt feeding unit, through the roll bring curled up into a tube billet steel, and then use the high frequency of proximity effect and skin effect make the strip edge instantaneous heating to welding temperature, and under the action of squeezing roller complete welding, then through water cooling, sizing and straightening as required specifications of the steel pipe. The product line in each units on the basis of digesting and absorbing domestic and foreign similar equipment, combined with China's national conditions, innovative design, convenient operation and maintenance, simple. The machine has high machining quality and assembly precision, and can produce electric welded steel pipe with high precision by adopting reasonable roll pass.



Production Process
Scroll up → Uncoil → Flattening → End Shear & Butt Welding → Accumulator → Forming → High-frequency induction welding→ Removing external burr → Cooling → Sizing → Cutting → Checking & Collecting → Accessing Warehouse



Cold Roll Cs 10-30m/Min 165mm Steel Pipe Manufacturing Machine 0



ERW Tube Mill Other Model



Model

Diameter Range

Pipe Thickness

Molding speed(m/min)

Motor Power(KW)

Mechanical area
(m³)

HG20

8-20MM

0.3-1MM

30-120

55

7×50

HG32

12-32MM

0.3-2.0MM

30-120

75

7×50

HG50

16-50MM

0.8-2.5MM

30-110

110

7×60

HG60

20-60MM

0.8-3MM

30-100

132

7×65

HG76

12-76MM

1-3MM

30-100

320

8×80

HG89

32-89MM

1-4MM

30-80

350

8×80

HG114

45-114MM

1.5-5.0MM

30-60

400

10×100

HG165

60-165MM

3-7MM

30-50

600

10×110

HG219

114-219MM

4-8MM

20-40

800

12×150

HG273

114-273MM

4-10MM

15-30

1000

18×160

HG325

165-325MM

4-12MM

10-30

1200

18×180

HG426

165-426MM

4-16MM

8-25

1400

18×180

HG508

219-508MM

4-20MM

8-20

2000

21×180
