150x150mm Adjustable Square Tube Mill for Carbon Steel Pipes

Name: 150x150mm Adjustable Square Tube Mill for Carbon Steel Pipes
Brand: Hebei Tengtian Welded Pipe Equipment Manufacturing Co.,Ltd.
SKU: LW600
Price: 50,000.00 USD
Availability: InStock

Product Details:

Place of Origin:	HEBEI,CHINA
Brand Name:	Tengtian
Certification:	CE ISO
Model Number:	LW600

Detail Information

Place of Origin:

HEBEI,CHINA

Brand Name:

Tengtian

Certification:

CE ISO

Model Number:

LW600

Mill Name:

Blue Carbon Steel Pipe Machine 150 * 150mm Pipe Adjustable Square Tube Mill

Product Speed:

Max 80m/min

Pipe Diameter:

60*60-150*150mm

Pipe Thickness:

2.0-7.0mm

Type Of Welding:

High Frequency Welding

Special Require:

Can Design According To The Customer

Highlight:

High Light

Highlight:

tube mill line

stainless steel pipe mill

Trading Information

Minimum Order Quantity:

1 set

Price:

$100000 to $1 million

Packaging Details:

packed in seaworthy material

Delivery Time:

three month

Payment Terms:

L/C,T/T,Western Union

Supply Ability:

200 set per year

Product Description

Blue Carbon Steel Pipe Machine 150 * 150mm Pipe Adjustable Square Tube Mill

Product Specifications

Attribute	Value
Mill Name	Blue Carbon Steel Pipe Machine 150 * 150mm Pipe Adjustable Square Tube Mill
Product Speed	Max 80m/min
Pipe Diameter	6060-150150mm
Pipe Thickness	2.0-7.0mm
Type of Welding	High frequency welding
Special Requirement	Can design according to customer specifications

Product Description

This advanced square and rectangular tube equipment combines international market demands with our company's LW series unit and FF forming technology. The automatic adjustment system significantly reduces product changeover time, improving efficiency and reducing production costs.

Key Advantages:

Produces different size tubes without roll changes
Uses one set of combined molds for multiple specifications
90% roller saving rate reduces tooling costs
Quick adjustment capability minimizes downtime

Production Process

Material (steel coil) → Uncoiler → Shear and Welder → Horizontal/Cage Accumulator → Forming Mill → HF Solid Welder → Sizing Mill → Rough Straightening (Turkey Head) → Cut Off Machine → Run Out Table

Technical Parameters

Parameter	Value
Stands of Forming Mill	7
Stands of Sizing Mill	5
Square Pipe Size	60×60-150×150mm
Square Pipe Thickness	2.0-7.0mm

ERW Tube Mill Models

Model	Diameter Range	Pipe Thickness	Line Speed (m/min)
LW200	3030-5050MM	1-3MM	20-80
LW600	6060-150150MM	2-7MM	20-60
LW800	8080-200200MM	1-3MM (or 4-13)	20-40
LW1000	100100-250250MM	3-12.7MM (or4-14)	15-30
LW1200	120120-300300MM	3-14MM	10-25
LW1400	150150-350350MM	4-14MM	8-20
LW1600	200200-400400MM	4-16MM	8-20

Note: Product specifications are adjustable. Our engineering team can design machines according to your special requirements.
