Steel Slitting Machine
>
Automatic Carbon Steel Slitting Machine 0.5-4.0mm 120m/min
  • Automatic Carbon Steel Slitting Machine 0.5-4.0mm 120m/min
  • Automatic Carbon Steel Slitting Machine 0.5-4.0mm 120m/min
  • Automatic Carbon Steel Slitting Machine 0.5-4.0mm 120m/min

Automatic Carbon Steel Slitting Machine 0.5-4.0mm 120m/min

Product Details:
Place of Origin: HEBEI,CHINA
Brand Name: Tengtian
Certification: CE ISO
Model Number: SJ1600*4
Detail Information
Place of Origin:
HEBEI,CHINA
Brand Name:
Tengtian
Certification:
CE ISO
Model Number:
SJ1600*4
Product Speed:
Max 120m/min
Steel Thickness:
0.5-4.0mm
Special Require:
Can Design According To The Customer
Type:
Carbon Steel Slitting Machine
Highlight:

High Light

Highlight:

sheet metal slitter machine

,

strip slitting machine

Trading Information
Minimum Order Quantity:
1 set
Price:
$100000 to $1 million
Packaging Details:
packed in seaworthy material
Delivery Time:
two months
Payment Terms:
Western Union,L/C,T/T
Supply Ability:
100 set per year
Product Description
Automatic Steel Coil Slitting Line / Cut To Length Line Machine
Product Specifications
Attribute Value
Product Speed Max 120m/min
Steel Thickness 0.5-4.0mm
Special Requirements Can be customized according to customer needs
Type Carbon Steel Slitting Machine
Detailed Technical Parameters
Material Stainless Steel
Thickness Range 0.2-2.0mm
Width 800mm
Entry Material 460-520mm
Recoiler Material 480-510mm
Max Diameter 1500mm
Max Weight of Entry Material 8T
Max Weight of Recoiler Material 8T
Cutting Speed 0~120m/min
Horizontal Beat ±0.01mm
Vertical Beat ±0.01mm
Voltage 380V
Container Size 1×20GP
Standard Components
  • Feeding trolley - 1 set
  • Hydraulic uncoiler - 1 set
  • Side guards & Slitting Machine - 1 set
  • Loop traversing crane - 1 Group
  • Separation device and the tension generator - 1 Group
  • Separation device & hydraulic recoiling machine - 1 Group
  • Discharge port trolley - 1 set
  • Hydraulic system - 1 set
  • Power control system - 1 set
  • Other components - 1 set
This production line is designed for metal plate decoiling, slitting, and winding into multiple coils of required width. Suitable for processing cold rolled and hot rolled carbon steel, silicon steel, tinplate, stainless steel, and various metal plates with surface treatments. The slitting line features PLC control with human-machine interface, offering high automation, simple operation, and reliable performance.
