Stainless Steel Tube Mill Machine for Round and Square Pipes 100m/min

Name: Stainless Steel Tube Mill Machine for Round and Square Pipes 100m/min
Brand: Hebei Tengtian Welded Pipe Equipment Manufacturing Co.,Ltd.
SKU: SSF60
Price: 50,000.00 USD
Availability: InStock

Product Details:

Place of Origin:	China
Brand Name:	TENG TIAN
Certification:	ISO9001/BV
Model Number:	SSF60

Detail Information

Place of Origin:

China

Brand Name:

TENG TIAN

Certification:

ISO9001/BV

Model Number:

SSF60

Product Name:

Stainless Steel Tube Mill Line Round Pipe Or Square Pipe Max Speed 100m/min Tube Mill Machine

After-sales Service Provided:

Engineers Available To Service Machinery Overseas

Pipe Material:

Carbon Steel

Voltage:

380V

Power(w):

400KW

Speed:

MAX 100 M / Min

Pipe Shape:

Round, Square & Rectangular

Round Pipe Diameter:

76mm-153mm

Warranty:

1 Year

Keywords:

Max Speed 100m/min Tube Mill Machine

Name:

Tube Mill Machine

Highlight:

High Light

Highlight:

Stainless Steel Tube Mill 100m/Min

400KW Stainless Steel Tube Mill

400KW Stainless Steel pipe Mill

Trading Information

Minimum Order Quantity:

1set

Price:

$100000 to $1 million

Packaging Details:

Seaworthy packing

Delivery Time:

3 months

Supply Ability:

150 units a year

Product Description

Round and Square Tube Mill Machine Line 100m/Min

Product Specifications

Attribute	Value
Product name	Stainless Steel Tube Mill Line Round Pipe or Square Pipe Max Speed 100m/min Tube Mill Machine
After-sales service	Engineers available to service machinery overseas
Pipe material	Carbon Steel
Voltage	380V
Power	400KW
Speed	MAX 100 m/min
Pipe Shape	Round, Square & Rectangular
Round Pipe Diameter	76mm-153mm
Warranty	1 year

Product Overview

This Tube Mill Machine produces stainless steel pipes with side lengths of 25x25-60x60mm and thicknesses of 0.5-3mm. The equipment features:

High precision and excellent stability
CNC machining center processed main components for superior accuracy
Servo motor driven mold and shaft to reduce manual replacement costs

Welded Pipe Mill Models

Serial No.	Model	Thickness (mm)	Specification (mm)	Speed (m/min)	Main Engine (kw)	Power (kw)	Area
1	H20	0.3-1	8-20	30-120	55	60	7*50
2	H32	0.3-2.0	12-32	30-120	75	100	7*50
3	H50	0.8-2.5	16-50	30-110	110	150	7*60
4	H60	0.8-3	20-60	30-100	132	200	7*65
5	H76	1-3	12-76	30-100	320	250	8*80
6	H89	1-4	32-89	30-80	350	300	8*80
7	HG114	1.5-5	45-114	30-60	400	300	10*100
8	HG165	3-7	60-165	30-50	600	400	10*110
9	HG219	4-8	114-219	20-40	800	500	12*150
10	HG273	4-10	114-273	15-30	1000	600	18*160
11	HG325	4-12	165-325	10-30	1200	600	18*180
12	HG426	4-16	165-426	8-25	1400	800	18*180
13	HG508	4-20	219-508	8-20	2000	1000	21*180

Production Process

Loading car
Uncoil
Cutting and Welding
Accumulator
Forming, HF welding, anneal welder, Deburring, Cooling, Sizing, Straightening
STD Cold-cutting saw
Transmitting
Hydrostatic testing
End facer
Straightener
Packing
Storage

Our Service Commitment

On-site engineer support for installation and operator training
One year quality guarantee with lifetime repair support
Comprehensive pre-sales and after-sales services including:
- Workshop and production output design
- Extended engineer support (months to 1 year)
- Project design for stainless/carbon steel pipe production
Responsibility for loading and shipping arrangements
