API 5L Hydrostatic Pipe Testing Machine for Steel Pipes 50-2400mm

Name: API 5L Hydrostatic Pipe Testing Machine for Steel Pipes 50-2400mm
Brand: Hebei Tengtian Welded Pipe Equipment Manufacturing Co.,Ltd.
SKU: LXSY-1800
Price: 50,000.00 USD
Availability: InStock

Product Details:

Place of Origin:	CHINA
Brand Name:	TENG TIAN
Certification:	CE / ISO9001
Model Number:	LXSY-1800

Detail Information

Place of Origin:

CHINA

Brand Name:

TENG TIAN

Certification:

CE / ISO9001

Model Number:

LXSY-1800

Product Name:

API 5L Hydrostatic Pipe Testing Machine For Steel Pipe Manufacturing Machine

Usage::

Perform Leaking And Hydraulic Pressure Test

Pipe Diameter:

50-610mm(ERW Mill) 219-2400 Mm (spiral Mill)

Pipe Length::

6-12m

Max. Testing Pressure::

20mpa, 50mpa, As Per Pipe Usage

Color:

Up To Client

Keyword:

Steel Pipe Manufacturing Machine

Highlight:

High Light

Highlight:

API 5L Steel Pipe Manufacturing Machine

Large Diameter Steel Pipe Manufacturing Machine

API 5L Steel Pipe Making Machine

Trading Information

Minimum Order Quantity:

1 Set

Price:

$100000 to $1 million

Packaging Details:

to be packed into container or in bulk cargo for oversize parts and delivered by sea/ railway

Delivery Time:

3 months

Supply Ability:

30 Set / Year

Product Description

API 5L Large Diameter Steel Pipe Manufacturing Machine / Metal Tube Making Machine

Product Specifications

Product Name: API 5L Hydrostatic Pipe Testing Machine for Steel Pipe Manufacturing Machine

Usage: Perform leaking and hydraulic pressure test

Pipe Diameter: 50-610mm (ERW Mill), 219-2400 mm (Spiral Mill)

Pipe Length: 6-12m

Max. Testing Pressure: 20mpa, 50mpa (as per pipe usage)

Color: Customizable per client requirements

Technical Specifications

Models of API 5L Hydrostatic Pipe Testing Machine for Steel Pipe Manufacturing Machine

Model	Specification(mm)	Length(m)	Pressure(Mpa)	Capacity(Kw)	Area(estimaterM)
ZFSY-100	Φ50~Φ114	6~12	≤50	65	5×12
ZFSY-160	Φ60~Φ168	6~12	≤50	65	5×12
ZFSY-220	Φ89~Φ219	6~12	≤50	75	5×12
ZFSY-350	Φ140~Φ355	6~12	≤70	85	6×20
ZFSY-400	Φ168~Φ426	8~12	≤70	65	6×22
ZFSY-500	Φ219~Φ508	8~12	≤70	85	6×22
ZFSY-600	Φ219~Φ610	8~12	≤70	100	6×22

Models of hydraulic tester for Spiral pipe welded mill

Model	Specification(mm)	Length(m)	Pressure(Mpa)	Capacity(Kw)	Area(estimaterM)
LXSY-400	Φ219~Φ426	6~12	≤50	65	5×12
LXSY-600	Φ219~Φ630	6~12	≤50	65	5×12
LXSY-800	Φ325~Φ820	6~12	≤50	75	5×12
LXSY-1000	Φ426~Φ1020	6~12	≤42	85	4×20
LXSY-1400	Φ508~Φ1420	8~12	≤21	65	4×22
LXSY-1800	Φ630~Φ1820	8~12	≤21	85	4×22
LXSY-2400	Φ720~Φ2400	8~12	≤21	100	4×22
LXSY-3000	Φ820~Φ3000	8~12	≤21	120	4×25
LXSY-3500	Φ1020~Φ3500	8~12	≤21	160	6×30

Product Overview

A hydraulic tester is used to perform leaking and hydraulic pressure test on ERW or spiral welded pipes. The test involves sealing the two ends of the pipe, filling the pipe with a liquid (usually water, which may be dyed to aid in visual leak detection), and pressurizing the vessel to the specified test pressure. Pressure tightness can be tested by shutting off the supply valve and observing whether there is a pressure loss. Our hydraulic tester meets API standards.

Key Differences Between ERW and Spiral Welded Pipe Testers

Longitudinal weld pipe hydraulic tester employs outside diameter sealing or sealing for big gaps. Hydraulic tester for spiral welding pipes uses polyurethane to seal the pipe end faces and has a system to maintain balance of oil and water.

Process Flow

Pipe installation
Sealing
Water filling
Pressurization
Pressure relief
Drainage
Pipe uninstallation
