800KW Pipe Mill Machine for Steel Pipes 10-50mm Diameter

Name: 800KW Pipe Mill Machine for Steel Pipes 10-50mm Diameter
Brand: Hebei Tengtian Welded Pipe Equipment Manufacturing Co.,Ltd.
SKU: HG50
Price: 50,000.00 USD
Availability: InStock

Product Details:

Place of Origin:	HEBEI,CHINA
Brand Name:	Tengtian
Certification:	CE ISO
Model Number:	HG50

Detail Information

Place of Origin:

HEBEI,CHINA

Brand Name:

Tengtian

Certification:

CE ISO

Model Number:

HG50

Product Name:

800KW Power Pipe Mill Machine Low Carbon Steel

Special Require:

Can Design According To The Customer

Material:

Steel Pipe,stainless Pipe

Product Speed:

Max 90m/min

Pipe Diameter:

10-50mm

Keyword:

Pipe Mill Machine

Highlight:

High Light

Highlight:

tube milling machine

steel pipe making machine

steel pipe manufacturing machine

Trading Information

Minimum Order Quantity:

1 set

Price:

$100000 to $1 million

Packaging Details:

packed in seaworthy material

Delivery Time:

one month

Supply Ability:

200 set per year

Product Description

800KW Power Pipe Mill Machine Low Carbon Steel

Product Attributes

Attribute	Value
Product Name	800KW Power Pipe Mill Machine Low carbon steel
Special Requirements	Can design according to customer specifications
Material	Steel pipe, Stainless pipe
Product Speed	Max 90m/min
Pipe Diameter	10-50mm

Product Overview

Model Number: G-400

Voltage: 380V 50hz

Rated Power: 3.0/4.0KW

Dimensions: 3.5m × 0.7m × 1.0m

Weight: 850KG

Certification: ISO9001:2008

Warranty: 2 Years

After-sales Service: Engineers available to service machinery overseas

Key Features

Long-term running with high speed and precision
Low fault rate and easy maintenance
Durable construction with excellent performance characteristics

Main Specifications

Parameter	Value
Cutting Length	0.5-32m (adjustable)
Cutting Precision	±3mm
Max Cutting Frequency	10 cuttings per minute
Max Speed	50m/min
Max Thickness of Pipes	6mm
Saw Head Action	Hydraulic Drive (Flat-pushing Manipulation)
Pipe Clamp	Hydraulic Clamping

Cold Cutting Saw Models

Model	Diameter Range (mm)	Thickness Range (mm)	Max. Speed	Motor	Saw Blade Dia. (mm)	Clamping Type
CS-32	12~38	0.4~2.0	120	YASKAWA/SIEMENS	350	Pneumatic
CS-50	20~63.5	0.6~2.0	100	YASKAWA/SIEMENS	400	Pneumatic/Hydraulic
CS-60	25~76	0.8~3.0	80	YASKAWA/SIEMENS	450	Pneumatic/Hydraulic
CS-76	25~76	0.8~4.0	80	YASKAWA/SIEMENS	450	Hydraulic
CS-114	50~114	1.2~5.0	60	YASKAWA/SIEMENS	600	Hydraulic

Note: Specifications are reference values. We customize each machine according to customer requirements.

Our Services

1. On-site installation and operator training by our engineers

2. One-year quality guarantee with lifetime repair service

3. Comprehensive pre-sales and after-sales support

4. Option for long-term engineer support (months to 1 year)

5. Complete project design for pipe manufacturing

6. Full responsibility for loading and shipping
