High Speed Pipe Making Machine for Carbon Steel Tubes 21-63mm

Name: High Speed Pipe Making Machine for Carbon Steel Tubes 21-63mm
Brand: Hebei Tengtian Welded Pipe Equipment Manufacturing Co.,Ltd.
SKU: HG60
Price: 50,000.00 USD
Availability: InStock

Product Details:

Place of Origin:	HEBEI,CHINA
Brand Name:	Tengtian
Certification:	CE, ISO9001, BV
Model Number:	HG60

Detail Information

Place of Origin:

HEBEI,CHINA

Brand Name:

Tengtian

Certification:

CE, ISO9001, BV

Model Number:

HG60

Product Name:

High Speed Pipe Making Machine For Carbon Furniture Tubes BV ISO Listed

Material:

Carbon Steel,stainless Steel,low Alloy Steel

Pipe Diameter:

21 - 63mm

Product Speed:

Max 50m/min

Max.Thickness For Square Pipe:

0.8-3.0mm

Certification:

CE ISO

Worm Gearing:

Max.80m/min

Keywords:

High Speed Pipe Making Machine

Highlight:

High Light

Highlight:

stainless tube mills

slitting line machine

Trading Information

Minimum Order Quantity:

1 set

Price:

$100000 to $1 million

Packaging Details:

Export waterproof and Seaworthy packing.

Delivery Time:

three months

Payment Terms:

L/C,T/T,Western Union

Supply Ability:

50 set per year

Product Description

High Speed Pipe Making Machine For Carbon Furniture Tubes BV ISO Listed

Product Specifications

Attribute	Value
Material	Carbon steel, stainless steel, low alloy steel
Pipe Diameter	21 - 63mm
Product Speed	Max 50m/min
Max. Thickness for Square Pipe	0.8-3.0mm
Certification	CE ISO
Worm Gearing	Max. 80m/min

Technical Specifications

Model	Diameter (mm)	Thickness (mm)	Speed (m/min)	Main Power (kw)	HF Welder (KW)	Area (m²)
HG32	10-32	0.4-1.5	30-100	250	100	12x100
HG50	12-50	0.6-2.5	30-90	300	150	12x100
HG76	12-76	1-3	30-90	320	200	12x100
HG89	32-89	1-4	30-80	350	300	12x100
HG114	45-114	1.5-5.0	30-60	400	300	12x100
HG165	60-165	3-7	30-50	600	400	12x100
HG219	114-219	4-8	20-40	800	500	15x150
HG273	114-273	4-10	15-30	1000	600	18x160
HG325	165-325	4-10	10-30	1200	600	12x100
HG426	165-426	4-12.7	8-25	1400	800	12x100
HG508	219-508	4-16	8-20	2000	1000	12x100

Frequently Asked Questions

Application: The HF (ERW) welded pipe forming machine produces building materials pipe, widely used for construction materials, drainage, energy supply pipes, building and decoration profiles, extruded profiles, and cold bending profiles.
Pipe Dimensions: Carbon steel pipe diameter can be customized from 25-606mm with wall thickness 0.5-25mm for various applications.
Raw Material: Machines can be customized to your requirements, with suitable steel strip width from 100mm to 1000mm, or designed according to your specifications.
After-Sales Service: Includes operation manuals and video tutorials. We provide free training at our plant and can send technicians to your site for installation and training (travel expenses to be covered by your company).
