1600mm Steel Slitting Machine

Name: 1600mm Steel Slitting Machine
Brand: Hebei Tengtian Welded Pipe Equipment Manufacturing Co.,Ltd.
SKU: SJ1600*4
Price: 50,000.00 USD
Availability: InStock

Product Details:

Place of Origin:	HEBEI,CHINA
Brand Name:	Tengtian
Certification:	CE ISO
Model Number:	SJ1600*4

Detail Information

Place of Origin:

HEBEI,CHINA

Brand Name:

Tengtian

Certification:

CE ISO

Model Number:

SJ1600*4

Material:

Carbon Steel,stainless Steel

Product Speed:

Max 120m/min

Steel Thickness:

0.5-4.0mm

Special Require:

Can Design According To The Customer

Type:

Carbon Steel Slitting Machine

Coil OD:

<2000mm

Highlight:

High Light

Highlight:

1600mm steel slitting machine

120m/min steel slitting machine

0.5mm steel slitting machine

Trading Information

Minimum Order Quantity:

1 set

Price:

$100000 to $1 million

Packaging Details:

packed in seaworthy material

Delivery Time:

two month

Payment Terms:

L/C, T/T, Western Union

Supply Ability:

150 set per year

Product Description

1600mm Sheet Cutting Slitting Machine Welded Carbon Steel Stainless Steel Material

Slitting Line:

Its function is to slit a wide coil tp stated width stripa coil along with the length direction which can be used for milling, welding pipe, cold bend forming, stamping as billet

Product Process:

Loading coil car→Uncoiler→Straightener device→Pinch roll&leveler & hydraulic shearer →Loop pit →Side guide →Slitter →Transition platform & scrap winder →Loop pit →Tension station→Recoiler→Unloading coil car

The Basic Parameters:

material	carbon steel,stainless steel,galvanized steel
material thickness	0.5-4.0mm
material width	900-1600mm
coil ID	Ø508/610MM
Coil OD	<2000mm
Coil weight	Max 24Ton

Other Model Of Slitting Line

Model	steel thickness	steel width	steel coil weight
3*1600mm	0.5-3.0mm	900-1600mm	30 Ton
4*1600mm	0.5-4.0mm	900-1600mm	30 Ton
6*1600mm	1-6mm	900-1600mm	30 Ton
8*2000mm	2-8mm	900-2000mm	35 Ton
10*2200mm	3-10mm	900-2200mm	35 Ton
12*2200mm	3-12mm	900-2200mm	35 Ton
16*2500mm	4-16mm	900-2500mm	35 Ton
20*2500mm	6-20mm	900-2500mm	35 Ton

This model just for you reference,the product range and thickness is adjustable,we have ourselves engineer team,can design the machine according to the customer special require.
