Carbon Steel Square Tube Mill Machine 30-120m/min Pipe Production Line

Name: Carbon Steel Square Tube Mill Machine 30-120m/min Pipe Production Line
Brand: Hebei Tengtian Welded Pipe Equipment Manufacturing Co.,Ltd.
SKU: HG50
Price: 50,000.00 USD
Availability: InStock

Product Details:

Place of Origin:	Hebei
Brand Name:	Tengtian
Certification:	CE,ISO9001,BV
Model Number:	HG50

Detail Information

Place of Origin:

Hebei

Brand Name:

Tengtian

Certification:

CE,ISO9001,BV

Model Number:

HG50

Mill Name:

Carbon Steel Square 2.5mm Tube Mill Machine 30mm/Min Steel Pipe Production Line

Control System:

PLC Control

Speed:

30-120m/min

Pipe Shape:

Round,square,rectangular

Pipe Diameter:

16-50mm

Thickness:

1.0-3.0mm

Welding Type:

High Frequency Welding

Cutting Saw:

Cold Saw & Friction Saw Cutting

Highlight:

High Light

Highlight:

2.5mm tube mill machine

30mm/min tube mill machine

HRC Tube Mill Machine

Trading Information

Minimum Order Quantity:

1 Set

Price:

$100000 to $1 million

Packaging Details:

Export waterproof and Seaworthy packing.

Delivery Time:

60 work days

Payment Terms:

L/C,T/T,Western Union

Supply Ability:

150 Sets/Year

Product Description

Carbon Steel Square 2.5mm Tube Mill Machine 30mm/Min Steel Pipe Production Line

Key Specifications

Attribute	Value
Control System	PLC Control
Production Speed	30-120m/min
Pipe Shapes	Round, Square, Rectangular
Pipe Diameter Range	16-50mm
Wall Thickness	1.0-3.0mm
Welding Type	High Frequency Welding
Cutting System	Cold Saw & Friction Saw Cutting

Product Overview

The HG50 High-Frequency Welded Pipe Production Line is designed for manufacturing welded pipes with diameters of 20-76mm and wall thicknesses of 0.6-3.0mm, including square, rectangular, and deformed pipes. This advanced production line incorporates innovative design and technology for superior performance and ease of operation.

Technical Specifications

Material Compatibility: Hot rolled or cold rolled steel strip (Low carbon steel and low alloy constructional steel)
Processing Range: Round pipe Φ20-76mm | Square/Rectangular pipe 20x20-60x60mm
Wall Thickness: Round pipe 0.6-3.0mm | Square/Rectangular pipe 0.6-2.5mm
Installed Capacity: 400KVA
Water Consumption: 30m³/h
High-Frequency Welder: 200KW solid-state
Workshop Requirements: 50-80m (L) × 12m (W) × 5m (H)
Forming Speed: 80-120m/min

Production Line Models

Model	Diameter (mm)	Thickness (mm)	Speed (m/min)	Main Power (kW)	HF Welder (KW)	Area (m²)
HG32	10-32	0.4-1.5	30-100	250	100	12×100
HG50	12-50	0.6-2.5	30-90	300	150	12×100
HG76	12-76	1-3	30-90	320	200	12×100
HG89	32-89	1-4	30-80	350	300	12×100
HG114	45-114	1.5-5.0	30-60	400	300	12×100
HG165	60-165	3-7	30-50	600	400	12×100
HG219	114-219	4-8	20-40	800	500	15×150
HG273	114-273	4-10	15-30	1000	600	18×160
HG325	165-325	4-10	10-30	1200	600	12×100
HG426	165-426	4-12.7	8-25	1400	800	12×100
HG508	219-508	4-16	8-20	2000	1000	12×100

Additional Information

Applicable Industries:

Building Material Shops, Manufacturing Plants, Machinery Repair Shops

Certifications:

ISO9001, CE

Warranty:

1 Year

After-sales Service:

Online support, Video technical support, Overseas engineer service

Supply Capacity:

200 Sets per Year (Delivery within 3.5 months)

Packaging:

Seaworthy nude packing with steel wire and wood block fixation, dustproof plastic covering

Shipping Port:

Tianjin port, China
