HG76 Welded Pipe Making Machine Or Steel Pipe Production Line for Square Tube

Large Image : HG76 Welded Pipe Making Machine Or Steel Pipe Production Line for Square Tube

Product Details:

Place of Origin:	China
Brand Name:	Tengtian
Certification:	CE / ISO
Model Number:	HG76

Payment & Shipping Terms:

Minimum Order Quantity:	1 Set
Price:	$100000 to $1 million
Packaging Details:	Special export packing, and fixed in container
Delivery Time:	2 Months - 4 Months
Payment Terms:	T/T, L/C
Supply Ability:	100 Sets/Year

Contact Now

Detailed Product Description

Roller Mill:	HG76 Welded Pipe Making Machine Or Steel Pipe Production Line For Square Tube	Voltage:	220/380/415/420/440V
Type:	Pipe Mill	Outer Diameter:	1000~1500mm
Inner Diameter:	480~520mm	Model:	ERW Welded Pipe Mill
Pipe Shape:	Rectangle, Round, Square	Material:	Carbon Steel
Production Capacity:	1-10m/min	Model Number:	HG32/HG50/HG76/HG127
Power:	7.5KW	Certification:	CE ISO9001
Warranty:	1 Year
Highlight:	hg76 Welded Pipe Making Machine , hg 76 , ERW Welded Pipe Making Machine

HG76 Welded Pipe Making Machine Or Steel Pipe Production Line for Square Tube

Product Description

HG76 Welded Pipe Making Machine Or Steel Pipe Production Line for Square Tube is used to manufacture of round pipe from cold-rolled and hot-rolled coil strip by means of unclosed tubular blank with its subsequent welding into tube, edge heating by means of solid state high-frequency welder, longitudinal seam welding in rolls of tube welding machine, cooling, further sizing or shaping and on-stream cutting of endless tube in measured lengths.

The High precision tube mill has some advantages as follow:

between level roller jumps 0.01,between frame and slide clearance ≤0.02mm, frame vertical degree ≤0.05, each frame parallel degree ≤0.1mm
steel pipe diameter and roundness error≤0.08mm.

Product Process:

material(steel coil)→uncoiler→shear and welder→horizontal(or cage) accumulator→forming mill→

HF soild welder→sizing mill→rounghly straightening(turkey head)→cut off machine→run out table

The Basic Parameters:

stands of forming mill	7
stands of sizing mill	5
shaft material	40Cr
round pipe diameter	19-76mm
Round pipe thickness	1.5-3.0mm
square pipe size	15×15-60×60mm
square pipe thickness	1.5-2.0mm

we can design the machine according to the customer detail require.

ERW Tube Mill Other Model:

Model	Diameter Range	Pipe Thickness	Line Speed(m/min)
HG20	8-25.4MM	0.3-1.2MM	120
HG32	10-32MM	1.4-1.5MM	120
HG50	16-76MM	0.7-2.5MM	30-120
HG76	25-76MM	1-4MM	30-100
HG89	32-89MM	1-4.5MM	30-80
HG114	45-114MM	1.5-5.0MM	30-60
HG165	60-165MM	3-7MM	30-50
HG219	114-219MM	4-8MM	20-40
HG273	114-273MM	4-10MM	15-30
HG325	165-325MM	4-10MM	10-30
HG426	165-426MM	4-12.7MM	8-25
HG508	219-508MM	4-16MM	8-20

Low carbon steel, low alloy steel, galvanized steel, stainless steel,etc.Applied raw material of erw pipe mill
