Tube Mill Welded Pipe Making Machine Application Architecture good Quality Steel

Large Image : Tube Mill Welded Pipe Making Machine Application Architecture good Quality Steel

Product Details:

Place of Origin:	China
Certification:	CE,BV, ISO
Model Number:	76

Payment & Shipping Terms:

Minimum Order Quantity:	1 set
Price:	$100000 to $1 million
Packaging Details:	Plastic film winding, wooden case for electronic components
Delivery Time:	90 days
Payment Terms:	L/C, T/T
Supply Ability:	25 sets per year

Contact Now

Detailed Product Description

Features:	FFX	Product:	Tube Mill Welded Pipe Making Machine Application Architecture Good Quality Steel
Keyword:	Tube Mill	Material:	Carbon Steel
Speed:	30-120 M/min	Thickness:	1-4 Mm
Motor:	400 KW	Application:	Application Architecture
Certificate:	CE	Keywords:	Tube Mill Welded Pipe Making
Highlight:	tube mill welded pipe making machine , Architecture Tube Mill , Architecture Welded Pipe Making Machine

tube mill welded pipe making machine application architecture good quality steel

2 Main Technical Specifications:

2.1 Main Specifications:

2.1.1 Pipe Diameter: Φ27 ～ 76mm( 3/4" ～ 2-1/2" )

2.1.2 Wall Thickness: 1.0～4.0mm

2.1.3 Pipe Length: 4 ～ 8mm

2.1.4 To-length Accuracy: 0 ～ 6mm ( STD )

2.2 Raw Material Conditions:Low carbon steel and low alloy constructional steel

2.2.1 Width of Strip: 100～ 280mm

2.2.2 Thickness of strip: 1.0～4.0mm

2.2.3 Inner Diameter of Coil: 520 ～ 650mm

2.2.4 Outer Diameter of Coil: 900 ～ 1800mm

2.2.5 Weigh of Coil: ≤3t

2.3 Forming Speed: 20 ～ 70m/min

2.4 Total Power: Approve 800KW

2.5 Compressed Air:

2.5.1 Flow Rate: 3m³/min

2.5.2 Pressure: 0.4 ～ 0.7MPa

2.6 Water Supply:

2.6.1 Circulation: 60t/h

2.6.2 Pressure: 0.1 ～ 0.25MPa

Tube Mill Welded Pipe Making Machine Application Architecture good Quality Steel 0

Tube Mill Welded Pipe Making Machine Application Architecture good Quality Steel 1

Tube Mill Welded Pipe Making Machine Application Architecture good Quality Steel 2

Tube Mill Welded Pipe Making Machine Application Architecture good Quality Steel 3

Tube Mill Welded Pipe Making Machine Application Architecture good Quality Steel 4

Tube Mill Welded Pipe Making Machine Application Architecture good Quality Steel 5
