Product Details:
Payment & Shipping Terms:
|
| Forming Method: | Steel Tube Making Machinery | Raw Material Thickness: | 2 - 20mm |
|---|---|---|---|
| Peoduct Name: | Tube Roller Mill | Model: | HG Series |
| Certification: | CE / ISO9001 / BV | Roll Weight(mm): | 30 |
| Highlight: | High Speed steel tube making machine,Custom metal steel tube making machine,High Speed steel pipe making machine |
||
Cold rolled forming technology is advanced and reliable. In order to ensure reliable performance, the abroach cold rolled section steel forming machine adopts PROFIBUS technology in its control system.
All of these ensured highly synchronization accuracy and the best product quality. All the indicators and operational costs are controlled at the lowest level. Hence, if you are looking for an economical cold rolled section steel forming machine, please try this one.
Technical specifications of abroach cold rolled section steel forming machine
| No. | Model | Pipe Size | Thickness | Speed(m/min) | Capacity(KW) | HF(KW) | Area |
| 1 | HG20 | ø8 - ø20 mm | 0.3 - 1.5 mm | 30 - 150 | 210 | 100 | 40*12 |
| 2 | HG32 | ø10 - ø32 mm | 0.4 - 2.0 mm | 30 - 150 | 300 | 150 | 40*12 |
| 3 | HG50 | ø16 - ø50 mm | 0.7 -2.5 mm | 30 - 150 | 410 | 200 | 60*12 |
| 4 | HG60 | ø22 - ø60 mm | 0.9 - 3.0 mm | 30 - 150 | 410 | 200 | 60*12 |
| 5 | HG76 | Ø25 - ø76 mm | 1 - 4 mm | 30 - 120 | 580 | 300 | 80*16 |
| 6 | HG89 | Ø32 - ø89 mm | 1 - 4.5 mm | 30 - 100 | 660 | 300 | 100*16 |
| 7 | HG114 | Ø45 - ø114 mm | 1.5 -5 mm | 30 - 80 | 920 | 400 | 100*16 |
| 8 | HG140 | Ø50 - ø140 mm | 1.5 - 5.5 mm | 30 - 80 | 920 | 400 | 100*16 |
| 9 | HG165 | Ø60 - ø165 mm | 2 - 6 mm | 30 - 60 | 1100 | 500 | 100*16 |
| 10 | HG219 | Ø114 - ø219mm | 3 - 8 mm | 20 - 45 | 1400 | 600 | 150*16 |
| 11 | HG273 | Ø114 - ø273mm | 4 - 12 mm | 15 - 30 | 2100 | 800 | 160*18 |
| 12 | HG325 | Ø165 - ø325 mm | 4 - 14 mm | 10 - 30 | 2500 | 1000 | 200*24 |
| 13 | HG426 | Ø165 - ø426 mm | 4 - 16 mm | 8 - 25 | 2900 | 1200 | 250*24 |
| 14 | HG508 | Ø219 - ø508 mm | 5 - 18 mm | 5 - 18 | 3400 | 1600 | 300*24 |
| 15 | HG610 | Ø355 - ø610 mm | 5 - 18 mm | 5 - 18 | 3700 | 1600 | 300*24 |
| 16 | HG760 | Ø426 - ø760 mm | 5 - 20 mm | 5 - 20 | 4300 | 1800 |
300*24 |
As an ISO9001:2008 certified abroach Steel Tube Making machine manufacture in China, we know the importance of product quality. In order to offer customers better quality, we carry out a series of measures, including employing highly experienced staff, utilizing advanced technology, and conducting strict quality inspections at each step of production, from raw material selection to final delivery. Hence, the quality of our products is ensured.
In addition to abroach Steel Tube Making machine, we manufacture other tube making machine products such as pipe making machine, and precision pipe mill etc.
Whenever you have a need for our products, please feel secure in contacting us
!
