Hydrostatic Tubing Testing Machine for Spiral Pipe 50-610mm

Name: Hydrostatic Tubing Testing Machine for Spiral Pipe 50-610mm
Brand: Hebei Tengtian Welded Pipe Equipment Manufacturing Co.,Ltd.
SKU: ZFSY-400
Price: 50,000.00 USD
Availability: InStock

Product Details:

Place of Origin:	CHINA
Brand Name:	TENG TIAN
Certification:	CE / ISO9001
Model Number:	ZFSY-400

Detail Information

Place of Origin:

CHINA

Brand Name:

TENG TIAN

Certification:

CE / ISO9001

Model Number:

ZFSY-400

Product Name:

Hydrostatic Tubing Testing Steel Pipe Manufacturing Machine For Spiral Pipe

Usage::

Perform Leaking And Hydraulic Pressure Test

Pipe Diameter:

50-610mm(ERW Mill) 219-2400 Mm (spiral Mill)

Pipe Length::

6-12m

Max. Testing Pressure::

20mpa, 50mpa, As Per Pipe Usage

Color:

Up To Client

Keyword:

Steel Pipe Manufacturing Machine

Highlight:

High Light

Highlight:

Spiral steel tube forming machine

Hydrostatic steel tube forming machine

Hydrostatic Steel Pipe Making Machine

Trading Information

Minimum Order Quantity:

1 Set

Price:

$100000 to $1 million

Packaging Details:

to be packed into container or in bulk cargo for oversize parts and delivered by sea/ railway

Delivery Time:

3 months

Supply Ability:

30 Set / Year

Product Description

Hydrostatic Tubing Testing Steel Tube Forming Machine For Spiral Pipe

Product Specifications

Product Name: Hydrostatic Tubing Testing Steel Pipe Manufacturing Machine for Spiral Pipe
Usage: Perform leaking and hydraulic pressure test
Pipe Diameter: 50-610mm (ERW Mill), 219-2400 mm (Spiral Mill)
Pipe Length: 6-12m
Max. Testing Pressure: 20MPa, 50MPa (as per pipe usage)
Color: Customizable to client requirements

Technical Specifications

Hydrostatic Tubing Testing Steel Pipe Manufacturing Machine Auxiliary Equipment

Model	Specification (mm)	Length (m)	Pressure (Mpa)	Capacity (Kw)	Area (estimated M)
ZFSY-100	Φ50~Φ114	6~12	≤50	65	5×12
ZFSY-160	Φ60~Φ168	6~12	≤50	65	5×12
ZFSY-220	Φ89~Φ219	6~12	≤50	75	5×12
ZFSY-350	Φ140~Φ355	6~12	≤70	85	6×20
ZFSY-400	Φ168~Φ426	8~12	≤70	65	6×22
ZFSY-500	Φ219~Φ508	8~12	≤70	85	6×22
ZFSY-600	Φ219~Φ610	8~12	≤70	100	6×22

Hydraulic Tester for Spiral Pipe Welded Mill

Model	Specification (mm)	Length (m)	Pressure (Mpa)	Capacity (Kw)	Area (estimated M)
LXSY-400	Φ219~Φ426	6~12	≤50	65	5×12
LXSY-600	Φ219~Φ630	6~12	≤50	65	5×12
LXSY-800	Φ325~Φ820	6~12	≤50	75	5×12
LXSY-1000	Φ426~Φ1020	6~12	≤42	85	4×20
LXSY-1400	Φ508~Φ1420	8~12	≤21	65	4×22
LXSY-1800	Φ630~Φ1820	8~12	≤21	85	4×22
LXSY-2400	Φ720~Φ2400	8~12	≤21	100	4×22
LXSY-3000	Φ820~Φ3000	8~12	≤21	120	4×25
LXSY-3500	Φ1020~Φ3500	8~12	≤21	160	6×30

Product Overview

The hydraulic tester is designed for performing leaking and hydraulic pressure tests on ERW or spiral welded pipes. The testing process involves sealing both ends of the pipe, filling it with liquid (typically water, sometimes dyed for better leak visibility), and pressurizing to the specified test pressure. Pressure tightness is verified by closing the supply valve and monitoring for pressure loss. Our hydraulic testers meet API standards for quality and performance.

Key Differences Between ERW and Spiral Welded Pipe Testers

Longitudinal weld pipe hydraulic testers utilize outside diameter sealing or sealing for large gaps. In contrast, spiral welding pipe hydraulic testers employ polyurethane to seal pipe end faces and incorporate a system to maintain oil and water balance.

Process Flow

Pipe installation
Sealing
Water filling
Pressurization
Pressure relief
Drainage
Pipe uninstallation
