High Precision Steel Pipe Manufacturing Machine 60-114mm Diameter

Name: High Precision Steel Pipe Manufacturing Machine 60-114mm Diameter
Brand: Hebei Tengtian Welded Pipe Equipment Manufacturing Co.,Ltd.
SKU: HG114
Price: 50,000.00 USD
Availability: InStock

Product Details:

Place of Origin:	HEBEI,CHINA
Brand Name:	Tengtian
Certification:	CE ISO
Model Number:	HG114

Detail Information

Place of Origin:

HEBEI,CHINA

Brand Name:

Tengtian

Certification:

CE ISO

Model Number:

HG114

Product Name:

High Precision Steel Pipe Manufacturing Machine Servo Motor Adjustment

Product Speed:

Max 80m/min

Pipe Diameter:

60-114mm

Pipe Thickness:

2.0-5.0mm

Type Of Welding:

High Frequency Welding

Keyword:

Steel Pipe Manufacturing Machine

Highlight:

High Light

Highlight:

High Precision Steel Pipe Manufacturing Machine

Servo Motor Steel Pipe Manufacturing Machine

High Precision steel pipe making machine

Trading Information

Minimum Order Quantity:

1 set

Price:

$100000 to $1 million

Packaging Details:

packed in seaworthy material

Delivery Time:

two month

Payment Terms:

L/C,T/T,Western Union

Supply Ability:

200 set per year

Product Description

High Precision Steel Pipe Manufacturing Machine Servo Motor Adjustment

Product Specifications

Attribute	Value
Product Name	High Precision Steel Pipe Manufacturing Machine Servo Motor Adjustment
Product Speed	Max 80m/min
Pipe Diameter	60-114mm
Pipe Thickness	2.0-5.0mm
Type of Welding	High Frequency Welding

Product Description

This Sheet Metal Straightener Mill Auxiliary Equipment is designed for steel pipe manufacturing, serving as the finishing equipment in welded steel pipe production lines. It effectively straightens steel pipes, eliminating longitudinal bends and correcting lateral profile irregularities after welding.

Tube Mill Production Process

Material (steel coil)
Uncoiler
Shear and welder
Horizontal (or cage) accumulator
Forming mill
HF solid welder
Sizing mill
Rough straightening (turkey head)
Cut off machine
Run out table

ERW Tube Mill Models

Model	Diameter Range	Pipe Thickness	Line Speed (m/min)
HG20	8-25.4MM	0.3-1.2MM	120
HG32	10-32MM	1.4-1.5MM	120
HG50	16-76MM	0.7-2.5MM	30-120
HG76	25-76MM	1-4MM	30-100
HG89	32-89MM	1-4.5MM	30-80
HG114	45-114MM	1.5-5.0MM	30-60
HG165	60-165MM	3-7MM	30-50
HG219	114-219MM	4-8MM	20-40
HG273	114-273MM	4-10MM	15-30
HG325	165-325MM	4-10MM	10-30
HG426	165-426MM	4-12.7MM	8-25
HG508	219-508MM	4-16MM	8-20

Note: The above models are for reference only. Product range and thickness are adjustable. Our engineering team can design machines according to specific customer requirements.
