Payment & Shipping Terms:
|Pipe Thickness:||1.0-3.0mm||Pipe Diameter:||10-50mm|
|Product Speed:||Max 90m/min||Material:||Steel Pipe,stainless Pipe|
|Special Require:||Can Design According To The Customer||Color:||Blue|
cold cutting machine,
cold cutting pipe equipment
Place of Origin:
After-sales Service Provided:
flying saw pipe making machine welding pipe machinery producing line online synchronous cutting machine
A: Film package+wooden package.
B: According to customer requirements
Long - term running with high speed and precision,low fault
Easy to operate and maintain
Long useful time,good characteristic
The main parameters of 540 Computer flying saw
1. Cutting Length: 0.5---32m Tunable
2. Cutting Precision: ±3mm
3. Max Cutting Frequency: 10 cuttings per min
4. Max Speed: 50m/min
5. Max Thickness of Pipes: 6 mm
6. Saw Head Action: Hydraulic Drive (Flat-pushing Manipulation)
7. Pipe Clamp: Hydraulic Clamping.
|Material:||HRC,CRC,||Motor Type:||Servo Motor|
|Cutting Speed:||Max50m/min||Warranty:||1 Year|
|Cutting Accuracy:||≤±2 Mm||After-sales Service Provided:||Engineers Available To Service Machinery Overseas|
|Saw Blade:||HSS / TCT Saw Blade||Square Pipe Size:||
50*50 - 150*150mm
Cold Cutting Saw for Pipe & Profiles:
Automated sawing tubes inline/offline & High Production.
High Speed Steel or Carbide Tipped Blades.
YASKAWA/SIEMENS servo motor & famous brand electric spare parts.
Almost fit for a variety of tube profiles.
Remove secondary chamfering or de-burring.
Carbon Steels, Stainless Steels, HSLA.
High speed and high precision cutting.
Excellent cutting edge, no burrs & save costs.
|Model||Diameter Range||Thickness Range||Max. Speed||Motor||Dia. Of Saw Blade mm||clamping Type|
|CS - 32||12~38||0.4~2.0||120||YASKAWA / SIEMEMS||350||Pneumatic|
|CS - 50||20~63.5||0.6~2.0||100||YASKAWA / SIEMEMS||400||Pneumatic or Hydraulic|
|CS - 60||25~76||0.8~3.0||80||YASKAWA / SIEMEMS||450||Pneumatic or Hydraulic|
|CS - 76||25~76||0.8~4.0||80||YASKAWA / SIEMEMS||450||Hydraulic|
|CS - 114||50~114||1.2~5.0||60||YASKAWA / SIEMEMS||600||Hydraulic|
Note: The data in the form just as reference according to general ranges, we always design and make each line according to each customer's specific requirements, so each customer can buy his own well-content Cold Saw from us.
1.) We will send the engineer for the installation and training your workers how to operate this machine in correct way.
2.) Warranty Team
One year quality guarantee, life guarantee repair. Within quality guarantee period, except for failures caused by human error, repair parts will be provided for free. After the quality guarantee period, only charge the cost of the spare parts.
3.) We supply the pre-sell and after-sell service.
pre-sell service: workshop design, and production output design
after-sell service: installation and training, and the skilled engineer for working.
4.) We can also sent the engineer working for you serval months or 1 year. The engineer will help you to improve the output, reduce the waste and decrease the cost.
5.) We supply the pre-sell service-Design for whole project for stainless steel pipe making/ carbon steel pipe making.
6.) We will be responsible for the loading and shipping
Contact Person: Ms.Xenia
