Pipe Mill Machine
>
Semi-Automatic Cold Cutting Saw for Steel Pipes 10-50mm

Semi-Automatic Cold Cutting Saw for Steel Pipes 10-50mm

Product Details:
Place of Origin: HEBEI,CHINA
Brand Name: Tengtian
Certification: CE ISO
Model Number: HG50
Detail Information
Place of Origin:
HEBEI,CHINA
Brand Name:
Tengtian
Certification:
CE ISO
Model Number:
HG50
Product Name:
Semi-Automatic Manual Metal Circular Cold Cutting Saw For Pipe Mill Machine
Pipe Diameter:
10-50mm
Product Speed:
Max 90m/min
Material:
Steel Pipe,stainless Pipe
Special Require:
Can Design According To The Customer
Keyword:
Cold Cutting Saw For Pipe Mill Machine
Highlight:

High Light

Highlight:

tube milling machine

,

steel pipe making machine

,

steel pipe manufacturing machine

Trading Information
Minimum Order Quantity:
1 set
Price:
$100000 to $1 million
Packaging Details:
packed in seaworthy material
Delivery Time:
one month
Payment Terms:
L/C,T/T
Supply Ability:
50 set per year
Product Description
Semi-Automatic Manual Metal Circular Cold Cutting Saw for Pipe Mill Machine
Product Specifications
Attribute Value
Pipe Diameter 10-50mm
Product Speed Max 90m/min
Material Compatibility Steel pipe, Stainless pipe
Customization Can be designed according to customer requirements
Key Features
  • Long-term high-speed precision operation with low fault rate
  • Easy operation and maintenance with long service life
  • Equipped with automatic feed and clamping devices for smooth operation
  • Bidirectional clamps ensure stable workpiece positioning without burrs
  • High cutting precision with cool cutting surface
  • Vertical knife-cutting method for efficient operation
  • Automatic stop, saw blade protection, and lubricating cooling functions
  • Capable of tail pulling operation
Main Parameters
Parameter Value
Cutting Length 0.5-32m (adjustable)
Cutting Precision ±3mm
Max Cutting Frequency 10 cuttings per minute
Max Speed 50m/min
Max Pipe Thickness 6mm
Saw Head Action Hydraulic Drive (Flat-pushing Manipulation)
Pipe Clamp Hydraulic Clamping
Technical Specifications
Material Compatibility HRC, CRC
Motor Type Servo Motor
Cutting Speed Max 50m/min
Warranty 1 Year
Round Pipe Size 60-165mm
Thickness Range 2.0-6.0mm
Cutting Accuracy ≤±2mm
Saw Blade Type HSS / TCT Saw Blade
Square Pipe Size 50×50 - 150×150mm
Model Specifications
Model Diameter Range (mm) Thickness Range (mm) Max. Speed (m/min) Motor Saw Blade Dia. (mm) Clamping Type
CS-32 12-38 0.4-2.0 120 YASKAWA/SIEMENS 350 Pneumatic
CS-50 20-63.5 0.6-2.0 100 YASKAWA/SIEMENS 400 Pneumatic/Hydraulic
CS-60 25-76 0.8-3.0 80 YASKAWA/SIEMENS 450 Pneumatic/Hydraulic
CS-76 25-76 0.8-4.0 80 YASKAWA/SIEMENS 450 Hydraulic
CS-114 50-114 1.2-5.0 60 YASKAWA/SIEMENS 600 Hydraulic
Note: Specifications are reference values. We customize each machine according to specific customer requirements.
Cold Cutting Saw Advantages
  • Automated sawing for both inline and offline operations
  • High-speed steel or carbide tipped blades
  • Premium YASKAWA/SIEMENS servo motors and electrical components
  • Versatile compatibility with various tube profiles
  • Eliminates need for secondary chamfering or de-burring
  • Handles carbon steels, stainless steels, and HSLA materials
  • Produces excellent cutting edges without burrs
Semi-Automatic Cold Cutting Saw for Steel Pipes 10-50mm 0
Our Services
  • On-site installation and operator training by our engineers
  • 1-year quality guarantee with lifetime repair support
  • Comprehensive pre-sales and after-sales services
  • Workshop and production output design consultation
  • Option for extended engineer support (several months to 1 year)
  • Complete project design for stainless/carbon steel pipe production
  • Responsible for loading and shipping arrangements
