High Frequency Welded Pipe Mill
>
High Precision ERW Tube Mill for Carbon Steel Pipes 21-63mm
High Precision ERW Tube Mill for Carbon Steel Pipes 21-63mm
  • High Precision ERW Tube Mill for Carbon Steel Pipes 21-63mm
  • High Precision ERW Tube Mill for Carbon Steel Pipes 21-63mm
  • High Precision ERW Tube Mill for Carbon Steel Pipes 21-63mm
  • High Precision ERW Tube Mill for Carbon Steel Pipes 21-63mm
  • High Precision ERW Tube Mill for Carbon Steel Pipes 21-63mm

High Precision ERW Tube Mill for Carbon Steel Pipes 21-63mm

Product Details:
Place of Origin: HEBEI,CHINA
Brand Name: Tengtian
Certification: CE, ISO9001, BV
Model Number: HG60
Detail Information
Place of Origin:
HEBEI,CHINA
Brand Name:
Tengtian
Certification:
CE, ISO9001, BV
Model Number:
HG60
Product Name:
High Frequency Welded Pipe Mill High Precision ERW Tube Mill / Straight Seam Welded ERW Pipe Mill Machine
Worm Gearing:
Max.80m/min
Certification:
CE ISO
Pipe Diameter:
21 - 63mm
Material:
Carbon Steel,stainless Steel,low Alloy Steel
Coil Thickness:
1-3 Mm
Max Size:
15x15-20x20mm φ17.2—φ60.3mm
Pipe Material:
Carbon Seteel
Fixed Cutting Length:
4-10m
Rectangular Tubes:
Min 10 X 15 ~ Max 40x 60 Mm
Dimension:
25m*2m*2m
Length Accuracy:
± 3mm
Production Name:
High Frequency Welded Pipe Mill
Round Pipe Size:
Φ20mm~Φ50mm * 0.8mm~2.5mm
Key Word:
High Frequency Welded Pipe Mill
Highlight:

High Light

Highlight:

High Precision erw tube mill

,

Straight Seam Welded erw tube mill

,

High Precision stainless steel tube mills

Trading Information
Minimum Order Quantity:
1 set
Price:
$100000 to $1 million
Packaging Details:
Export waterproof and Seaworthy packing.
Delivery Time:
3 months
Payment Terms:
L/C,T/T,Western Union
Supply Ability:
30 set per year
Product Description
High Precision ERW Tube Mill / Straight Seam Welded ERW Pipe Mill Machine
Product Specifications
Attribute Value
Worm Gearing Max. 80m/min
Certification CE ISO
Pipe Diameter 21 - 63mm
Material Carbon steel, stainless steel, low alloy steel
Coil Thickness 1-3 mm
Max Size 15x15-20x20mm φ17.2—φ60.3mm
Fixed Cutting Length 4-10m
Rectangular Tubes Min 10 x 15 ~ Max 40x 60 mm
Dimension 25m*2m*2m
Length Accuracy ± 3mm
Round Pipe Size Φ20mm~Φ50mm * 0.8mm~2.5mm
Product Description

Our high frequency welded pipe mill utilizes advanced welding technology with dual welding arcs, delivering increased speed, higher deposition, and superior mechanical properties. Ideal for producing tubes used in heat exchangers, refrigerators, automotive frames, bicycles, fitness equipment, furniture, cooling machines, petrol transmission, and construction applications.

Key Features
  • Continuous production capability without roller changes in rough-forming section
  • Reliable welding seam technology ensuring consistent quality
  • Produces most stainless steel pipes currently used in building construction
  • Low production cost with high production capacity
Technical Parameters
Model Diameter(mm) Thickness(mm) Speed(m/min) Main power(kw) HF welder(KW) Area(m2)
HG32 10-32 0.4-1.5 30-100 250 100 12x100
HG50 12-50 0.6-2.5 30-90 300 150 12x100
HG76 12-76 1-3 30-90 320 200 12x100
HG89 32-89 1-4 30-80 350 300 12x100
HG114 45-114 1.5-5.0 30-60 400 300 12x100
HG165 60-165 3-7 30-50 600 400 12x100
Working Process
High Precision ERW Tube Mill for Carbon Steel Pipes 21-63mm 0
Process Flow
High Precision ERW Tube Mill for Carbon Steel Pipes 21-63mm 1
Our Workshop
High Precision ERW Tube Mill for Carbon Steel Pipes 21-63mm 2 High Precision ERW Tube Mill for Carbon Steel Pipes 21-63mm 3
Our Services
  • On-site installation and operator training by our engineers
  • One year quality guarantee with lifetime repair service
  • Comprehensive pre-sale and after-sale support including workshop design and production output planning
  • Option for extended engineer support to improve output and reduce waste
  • Complete project design services for stainless steel/carbon steel pipe production
  • Responsible for loading and shipping arrangements

For professional advice and inquiries, please contact us.
