Carbon Steel ERW Pipe Mill 25-76mm Diameter 50m/min Speed

Name: Carbon Steel ERW Pipe Mill 25-76mm Diameter 50m/min Speed
Brand: Hebei Tengtian Welded Pipe Equipment Manufacturing Co.,Ltd.
SKU: HG76
Price: 50,000.00 USD
Availability: InStock

Product Details:

Place of Origin:	HEBEI,CHINA
Brand Name:	Tengtian
Certification:	CE, ISO9001, BV
Model Number:	HG76

Detail Information

Place of Origin:

HEBEI,CHINA

Brand Name:

Tengtian

Certification:

CE, ISO9001, BV

Model Number:

HG76

Product Name:

Carbon Steel ERW Pipe Mill , Tube Making Machine 40Cr Shaft Material

Pipe Diameter:

25-76mm

Product Speed:

Max 50m/min

Material:

Carbon Steel,stainless Steel,low Alloy Steel

Cutting Saw:

Friction Saw Cutting

Worm Gearing:

Max.80m/min

Pipe Thickness:

4.0-10.0mm

Keywords:

Carbon Steel ERW Pipe Mill

Highlight:

High Light

Highlight:

stainless tube mills

slitting line machine

Trading Information

Minimum Order Quantity:

1 set

Price:

$100000 to $1 million

Packaging Details:

Export waterproof and Seaworthy packing.

Delivery Time:

three months

Payment Terms:

L/C,T/T,Western Union,

Supply Ability:

50 set per year

Product Description

Carbon Steel ERW Pipe Mill, Tube Making Machine 40Cr Shaft Material

Product Specifications

Attribute	Value
Pipe Diameter	25-76mm
Product Speed	Max 50m/min
Material Compatibility	Carbon steel, stainless steel, low alloy steel
Cutting Saw	Friction Saw Cutting
Worm Gearing	Max. 80m/min
Pipe Thickness	4.0-10.0mm

Production Process

material(steel coil) → uncoiler → shear and welder → horizontal(or cage) accumulator → forming mill → HF solid welder → sizing mill → roughly straightening(turkey head) → cut off machine → run out table

Technical Parameters

Stands of forming mill	7
Stands of sizing mill	5
Shaft material	40Cr
Round pipe diameter	19-76mm
Round pipe thickness	1.5-3.0mm
Square pipe size	15×15-60×60mm
Square pipe thickness	1.5-2.0mm

We can design the machine according to customer requirements.

Available ERW Tube Mill Models

Model	Diameter Range	Pipe Thickness	Line Speed (m/min)
HG20	8-25.4MM	0.3-1.2MM	120
HG32	10-32MM	1.4-1.5MM	120
HG50	16-76MM	0.7-2.5MM	30-120
HG76	25-76MM	1-4MM	30-100
HG89	32-89MM	1-4.5MM	30-80
HG114	45-114MM	1.5-5.0MM	30-60
HG165	60-165MM	3-7MM	30-50
HG219	114-219MM	4-8MM	20-40
HG273	114-273MM	4-10MM	15-30
HG325	165-325MM	4-10MM	10-30
HG426	165-426MM	4-12.7MM	8-25
HG508	219-508MM	4-16MM	8-20

Our Services

Quality Assurance

We guarantee the quality of our products for one year after successful installation and debugging. We will be responsible for any quality problems resulting from design and manufacturing defects, including all expenses for replacing parts and components (excluding human factors and vulnerable components).

Installation & Debugging

Factory will send 1-2 technical engineers for installation and testing operation
The buyer is responsible for:
- Site preparation and equipment foundation
- Cool constructions according to equipment material provided by supplier
- Installation equipment (lift equipment, tools, etc.)
- Installation accessory materials (wires, drive pipes, water pipes, etc.)
- Labor force arrangement
The buyer must provide:
- Power supply to equipment interface connector
- Water supply to equipment interface connector
- Gas supply to equipment interface connector

Buyer Preparation Notes

Machinery device location (length × width)
Power supply: Main power to equipment control bench, unit position
Air feed: Air compressor (1.5 cubic meters/minutes)
Water supply: Water source to machine station
