Galvanized Steel ERW Pipe Mill For 60mm Round Pipe 3mm Thickness

Galvanized Steel ERW Pipe Mill For 60mm Round Pipe 3mm Thickness
Galvanized Steel ERW Pipe Mill For 60mm Round Pipe 3mm Thickness

Large Image :  Galvanized Steel ERW Pipe Mill For 60mm Round Pipe 3mm Thickness

Product Details:
Place of Origin: China
Brand Name: TENGTIAN
Certification: CE ISO9000 BV
Model Number: HG60
Payment & Shipping Terms:
Minimum Order Quantity: 1 set
Packaging Details: standard export package
Delivery Time: 90 wording days
Payment Terms: L/C, T/T, Western Union, MoneyGram
Supply Ability: 5 set/month
Detailed Product Description
Machine Name: ERW Pipe Mill Product: Steel Round Pipe And Square Pipe
Feature: Precision Material: Carbon Steel And Galvanized Steel
Other Pipe: Rectangular Pipe Max Size: 60mm
Thickness: 3mm Length: 3-6m
Rollers: Not Include Model: 60
Key Words: ERW Pipe Mill
High Light:

3mm Thickness ERW Pipe Mill

,

60mm Max ERW Pipe Mill

,

ERW Pipe Mill Galvanized Steel

Steel Tube By ERW Pipe Mill For 60mm Round Pipe

ERW Pipe Mill General Introduction



HG60 High-Frequency Welded Pipe Production Line is designed to produce round pipe 25-60mm and according size square pipe , thickness 1-3mm. Adopting roll pass design, the production line can manufacture welded steel pipes with good quality machining and high precision assembling.



According to the designing guideline of improving the operating character & environment and the safety & producing character , reducing the cost of the roller to guarantee high efficiency,HG50 production line adopts the double-radius hole style of design .


Round pipe:15-60mm



Square pipe :10x10  15x15  20x20  40x40mm

Rec Pipe:20x10  20x30mm

Thickness:1-3mm

ERW Pipe Mill Main Parameters and Specifications



(1)Material Specifications:

Standard

Internatioanl standard tube mill machine

Material

galvanized steel

Mechanical properties

σb≤520Mpa,σs≤365MPa

Strip Width

50-120mm

Strip Thickness:

1-3mm

Inner Diameter of Coils

Φ508mm

Outer Diameter of Coils

Φ1300~φ2000mm

Coil Weight

≤5T

(2)Pipe Specification

Pipe Diameter

round pipe :60mm



Square pipe :10x10 15x15 20x20 30x30  40x40mm

Rec Pipe:20x10 20x30mm


Length

3-6m

Pipe-cutting Precision

0-6mm

Forming Speed

max 80m/min for 1 mm thickness

(3)The buyer should self-supply

Work shop

60x12m, H>5m(crane to ground)

Power

Approx.3500KW 380V/60Hz/3phases

Circulation Cooling Water(whole system)

Flow:30+30 CBM
Pool Volume:40m3

Compressed Air
(whole system)

Flow:5m3/min
Pressure: 5-7kg/ cm2

Cable

All cable outside of my machine, you buy after machine fix location.



ERW pipe mill Working Process for ERW pipe mill



strip steel to coil→uncoiler →end straightener→flattener→shear welder→storage material unit →formed,welding,cooling,accurate pipe Dia. size →accurate pipe length size,cutting→inspection →package



ERW Pipe mill

Galvanized Steel ERW Pipe Mill For 60mm Round Pipe 3mm Thickness 0Galvanized Steel ERW Pipe Mill For 60mm Round Pipe 3mm Thickness 1










Our Factory for ERW Pipe Mill

Galvanized Steel ERW Pipe Mill For 60mm Round Pipe 3mm Thickness 2


Our Office
Galvanized Steel ERW Pipe Mill For 60mm Round Pipe 3mm Thickness 3


Our Team
Galvanized Steel ERW Pipe Mill For 60mm Round Pipe 3mm Thickness 4



Past Project for ERW pipe mill
Galvanized Steel ERW Pipe Mill For 60mm Round Pipe 3mm Thickness 5

ERW Pipe Mill and Management Certificate

Galvanized Steel ERW Pipe Mill For 60mm Round Pipe 3mm Thickness 6
