Precision Round Tube Mill for Galvanized Steel 25-89mm

Name: Precision Round Tube Mill for Galvanized Steel 25-89mm
Brand: Hebei Tengtian Welded Pipe Equipment Manufacturing Co.,Ltd.
SKU: HG89
Price: 50,000.00 USD
Availability: InStock

Product Details:

Place of Origin:	China
Brand Name:	TENGTIAN
Certification:	CE ISO9000 BV
Model Number:	HG89

Detail Information

Place of Origin:

China

Brand Name:

TENGTIAN

Certification:

CE ISO9000 BV

Model Number:

HG89

Machine Name:

Precision Round Tube Mill By Galvanized Steel Strip Rolling Forming

Product:

Round Pipe And Square Pipe

Feature:

Precision

Material:

Carbon Steel And Galvanized Steel

Other Pipe:

Rectangular Pipe

Max Size:

89mm

Thickness:

1-3mm

Length:

3-6m

Rollers:

Not Include

Model:

89mm

Keywords:

Precision Tube Mill

Highlight:

High Light

Highlight:

89mm Round Tube Mill

Precision Round Tube Mill

High Frequency Welded Pipe Mill 89mm

Trading Information

Minimum Order Quantity:

1 set

Price:

$100000 to $1 million

Packaging Details:

standard export package

Delivery Time:

90 wording days

Payment Terms:

L/C,T/T,Western Union,MoneyGram

Supply Ability:

5 set/month

Product Description

Precision Round Tube Mill By Galvanized Steel Strip Rolling Forming

Product Specifications

Attribute	Value
Machine Name	Precision Round Tube Mill By Galvanized Steel Strip Rolling Forming
Product	Round pipe and square pipe
Feature	Precision
Material	Carbon steel and galvanized steel
Other pipe	Rectangular pipe
Max size	89mm
Thickness	1-3mm
Length	3-6m
Rollers	Not included
Model	89mm

Product Description

The HG89 High-Frequency Welded Pipe Production Line is engineered to manufacture precision square pipes ranging from 30-89mm with thickness of 1-3mm. Utilizing advanced roll pass design, this production line delivers welded steel pipes with exceptional quality machining and high precision assembly.

Key Features

Double-radius hole style design for improved efficiency
Optimized operating characteristics and safety features
Reduced roller costs while maintaining high productivity

Technical Specifications

Material Specifications
Standard	International standard tube mill machine
Material	Galvanized steel
Mechanical properties	σb≤520Mpa, σs≤365MPa
Strip Width	60-280mm
Strip Thickness	1-3mm
Inner Diameter of Coils	Φ508mm
Outer Diameter of Coils	Φ1300～φ2000mm
Coil Weight	≤5T
Pipe Specification
Pipe Diameter	25-89mm
Length	3-6m
Pipe-cutting Precision	0-6mm
Forming Speed	Max 80m/min for 2mm thickness
