Home > products >
Automatic Tube Mill
>
High Frequency Automatic Tube Mill 76mm-153mm for Carbon Steel Pipes
High Frequency Automatic Tube Mill 76mm-153mm for Carbon Steel Pipes
  • High Frequency Automatic Tube Mill 76mm-153mm for Carbon Steel Pipes
  • High Frequency Automatic Tube Mill 76mm-153mm for Carbon Steel Pipes
  • High Frequency Automatic Tube Mill 76mm-153mm for Carbon Steel Pipes

High Frequency Automatic Tube Mill 76mm-153mm for Carbon Steel Pipes

Product Details:
Place of Origin: China
Brand Name: TENG TIAN
Certification: ISO9001/BV
Model Number: HG153
Detail Information
Place of Origin:
China
Brand Name:
TENG TIAN
Certification:
ISO9001/BV
Model Number:
HG153
Mill Name:
Green Large High Frequency Automatic Tube Mill Diameter 76mm-153mm Hg153
After-sales Service Provided:
On-Site Engineers
Pipe Material:
Carbon Steel
Voltage:
380V
Power(w):
1500KW
Speed:
10-60m / Min
Pipe Shape:
Round, Square & Rectangular
Round Pipe Diameter:
76mm-153mm
Warranty:
1 Year
Keywords:
Diameter 76mm-153mm Automatic Tube Mill
Highlight:

High Light

Highlight:

76mm High Frequency Tube Mill

,

153mm High Frequency Tube Mill

,

153mm hf welded tube mill

Trading Information
Minimum Order Quantity:
1set
Price:
$100000 to $1 million
Packaging Details:
Seaworthy packing
Delivery Time:
3 months
Supply Ability:
150 units a year
Product Description
Green Large High Frequency Automatic Tube Mill Diameter 76mm-153mm Hg153
Product Attributes
Mill Name Green Large High Frequency Automatic Tube Mill Diameter 76mm-153mm Hg153
After-sales service provided On-Site Engineers
Pipe material Carbon Steel
Voltage 380V
Power 1500KW
Speed 10-60m / min
Pipe Shape Round, Square & Rectangular
Round Pipe Diameter 76mm-153mm
Warranty 1 year
Product Information

The Green Large High Frequency Automatic Tube Mill Diameter 76mm-153mm Hg153 is engineered to produce welded square pipes with side lengths of 60*60-120*120mm and wall thicknesses of 1.2～4.5mm, as well as round, rectangular, and deformed pipes of corresponding sizes. Featuring an advanced roll pass design, this production line delivers welded steel pipes with exceptional machining quality and high-precision assembly.

Model Specifications
Serial number Model Thickness(mm) Specification(mm) Speed(m/min) Main Engine(kw) Power(kw) Area
1 H20 0.3-1 8-20 30-120 55 60 7*50
2 H32 0.3-2.0 12-32 30-120 75 100 7*50
3 H50 0.8-2.5 16-50 30-110 110 150 7*60
4 H60 0.8-3 20-60 30-100 132 200 7*65
5 H76 1-3 12-76 30-100 320 250 8*80
6 H89 1-4 32-89 30-80 350 300 8*80
7 HG114 1.5-5 45-114 30-60 400 300 10*100
8 HG165 3-7 60-165 30-50 600 400 10*110
9 HG219 4-8 114-219 20-40 800 500 12*150
10 HG273 4-10 114-273 15-30 1000 600 18*160
11 HG325 4-12 165-325 10-30 1200 600 18*180
12 HG426 4-16 165-426 8-25 1400 800 18*180
13 HG508 4-20 219-508 8-20 2000 1000 21*180
Production Process
  • Loading car
  • Uncoil
  • Cutting and Welding
  • Accumulator
  • Forming, HF welding, anneal welder, Deburring, Cooling, Sizing, Straightening
  • STD Cold-cutting saw
  • Transmitting
  • Hydrostatic testing
  • End facer
  • Straightener
  • Packing
  • Storage
High Frequency Automatic Tube Mill 76mm-153mm for Carbon Steel Pipes 0
Our Service
  • On-site engineer support for installation and operator training
  • One-year quality guarantee with lifetime repair service
  • Comprehensive pre-sales and after-sales support including workshop design and production output planning
  • Option for extended engineer support to optimize production output and reduce waste
  • Complete project design services for stainless steel and carbon steel pipe manufacturing
  • Full responsibility for loading and shipping arrangements
High Frequency Automatic Tube Mill 76mm-153mm for Carbon Steel Pipes 1 High Frequency Automatic Tube Mill 76mm-153mm for Carbon Steel Pipes 2
