Product Details:
Payment & Shipping Terms:
|
| Product Name: | Plate Cutting Max. 90m/Min 3X1500mm Steel Coil Slitting Machine | Applicable Materials: | Cold Rolled Carbon Steel, Galvanised Coils, Pre-painted Coils |
|---|---|---|---|
| Equipment Specification: | Customer Specified | Thickness Of Strip: | 0.5 - 3 Mm |
| Coil Weight: | Max. 22,000kg | Speed: | 90m/min |
| Warranty: | One Year | Key Words: | 3X1500mm Steel Coil Slitting Machine |
| High Light: | 3X1500mm Steel Coil Slitting Machine,90m/Min Steel Coil Slitting Machine,steel coil slitting line Power Saving |
||
GENERAL SPECIFICATION INPUT DATE
| Material | Cold Rolled carbon Steel, Galvanised Coils, pre-painted coils |
| Tensile strength | 550Mpa |
| Yield strength | 300Mpa |
| Thickness of strip | 0.70 - 3.00mm |
| Width of strip | 600 ~ 1500mm |
| Coil weight | Max. 22,000kg |
| Coil inside diameter | 508/610mm |
| Coil outside diameter | 700~1,800mm |
PRODUCT DATA
| Recoiling inside diameter | 508mm |
| Recoiling outside diameter | Max.1,600mm |
| Recoiling weight | Max. 20,000kg |
| Min. slitting width | 50mm |
| Slitting capacity |
20slits for thickness 1mm 12slits for thickness 2mm 5 slits for thickness 3mm |
TOLERANCES
| Slitting width accuracy | +/ - 0.05mm slitting width (thickness ≤1.5mm) +/ - 0.1mm slitting width (thickness >1.6mm) |
| Edge burr | <5% thickness (Min 0.03mm) |
LINE SPEEDS
| Processing speed | Max. 90m/min |
| Threading speed | 10m/min |
OTHERS
| Pass line height | 1,000mm above floor level |
| Line direction | From “ ” to “ ” from the view of operator side |
| Painting color | as required |
|
Required Utilities
|
Power supply 3ph AC380V 50Hz Capacity 220 kw |
|
Compressed air pressure 0.5~0.7Mpa Capacity 0.5M3/min |
