120m/min Tube Mill Machine for 76mm-153mm Steel Pipes

Name: 120m/min Tube Mill Machine for 76mm-153mm Steel Pipes
Brand: Hebei Tengtian Welded Pipe Equipment Manufacturing Co.,Ltd.
SKU: HG153
Price: 50,000.00 USD
Availability: InStock

Product Details:

Place of Origin:	China
Brand Name:	TENG TIAN
Certification:	ISO9001/BV
Model Number:	HG153

Detail Information

Place of Origin:

China

Brand Name:

TENG TIAN

Certification:

ISO9001/BV

Model Number:

HG153

Product Name:

Blue Tube Mill Machine 76mm- 153mm Steel Pipe Production Line Tube Mill Machine

After-sales Service Provided:

Engineers Available To Service Machinery Overseas

Pipe Material:

Carbon Steel

Voltage:

380V

Power(w):

400KW

Speed:

120m / Min

Pipe Shape:

Round, Square & Rectangular

Round Pipe Diameter:

76mm-153mm

Warranty:

1 Year

Keywords:

Speed 120m/min Tube Mill Machine

Highlight:

High Light

Highlight:

120m/min Steel Tube Mill

153mm Steel Pipe Production Line

153mm Steel Tube Mill

Trading Information

Minimum Order Quantity:

1set

Price:

$100000 to $1 million

Packaging Details:

Seaworthy packing

Delivery Time:

3 months

Supply Ability:

150 units a year

Product Description

Blue Tube Mill Machine 76mm-153mm Steel Pipe Production Line

High-speed 120m/min steel tube mill machine for producing round, square, and rectangular pipes with diameters from 76mm to 153mm.

Key Specifications

Attribute	Value
Product Name	Blue Tube Mill Machine 76mm-153mm Steel Pipe Production Line
After-sales Service	Engineers available to service machinery overseas
Pipe Material	Carbon Steel
Voltage	380V
Power	400KW
Speed	120m/min
Pipe Shapes	Round, Square & Rectangular
Round Pipe Diameter	76mm-153mm
Warranty	1 year

Product Information

The HG153 High-Frequency Welded Pipe Mill Line produces welded square pipes of 60×60-120×120mm in side length and 1.2-4.5mm wall thickness, along with round, rectangular, and deformed pipes of corresponding sizes. Featuring advanced roll pass design, this production line delivers high-quality welded steel pipes with precision machining and assembly.

Available Models

Serial No.	Model	Thickness (mm)	Specification (mm)	Speed (m/min)	Main Engine (kw)	Power (kw)	Area
1	H20	0.3-1	8-20	30-120	55	60	7×50
2	H32	0.3-2.0	12-32	30-120	75	100	7×50
3	H50	0.8-2.5	16-50	30-110	110	150	7×60
4	H60	0.8-3	20-60	30-100	132	200	7×65
5	H76	1-3	12-76	30-100	320	250	8×80
6	H89	1-4	32-89	30-80	350	300	8×80
7	HG114	1.5-5	45-114	30-60	400	300	10×100
8	HG165	3-7	60-165	30-50	600	400	10×110
9	HG219	4-8	114-219	20-40	800	500	12×150
10	HG273	4-10	114-273	15-30	1000	600	18×160
11	HG325	4-12	165-325	10-30	1200	600	18×180
12	HG426	4-16	165-426	8-25	1400	800	18×180
13	HG508	4-20	219-508	8-20	2000	1000	21×180

Production Process

Loading car → Uncoil → Cutting and Welding → Accumulator → Forming, HF welding, anneal welder, Deburring, Cooling, Sizing, Straightening → STD Cold-cutting saw → Transmitting → Hydrostatic testing → End facer → Straightener → Packing → Storage

Our Service Commitment

On-site engineer support for installation and operator training
One year quality guarantee with lifetime repair support
Comprehensive pre-sales and after-sales services including workshop design and production output planning
Option for extended engineer support (several months to 1 year) to optimize output and reduce waste
Complete project design services for stainless steel and carbon steel pipe production
Full responsibility for loading and shipping arrangements
