500x500mm Precision Welded Steel Square Tube Mill for Carbon and Galvanized Steel

Name: 500x500mm Precision Welded Steel Square Tube Mill for Carbon and Galvanized Steel
Brand: Hebei Tengtian Welded Pipe Equipment Manufacturing Co.,Ltd.
SKU: 500x500
Price: 50,000.00 USD
Availability: InStock

Product Details:

Place of Origin:	China
Brand Name:	TENGTIAN
Certification:	CE ISO9000 BV
Model Number:	500x500

Detail Information

Place of Origin:

China

Brand Name:

TENGTIAN

Certification:

CE ISO9000 BV

Model Number:

500x500

Machine Name:

500x500mm Welded Steel Square Tube Mill By GI Steel Coil

Product:

Square Tube

Feature:

Precision

Material:

Carbon Steel And Galvanized Steel

Other Pipe:

Square Pipe

Max Size:

500x500mm

Thickness:

3mm

Length:

6-12m

Rollers:

Not Include

Model:

500x500

Key Words:

500x500mm Welded Steel Square Tube Mill By GI Steel Coil

Highlight:

High Light

Highlight:

500x500mm Square Tube Mill

500x500mm Tube Mill equipment

precision Square Tube Mill Equipment

Trading Information

Minimum Order Quantity:

1 set

Price:

$100000 to $1 million

Packaging Details:

standard export package

Delivery Time:

90 wording days

Payment Terms:

L/C,T/T,Western Union,MoneyGram

Supply Ability:

5 set/month

Product Description

Precision 500x500mm Welded Steel Square Tube Mill Equipment By GI Steel Coil

Product Specifications

Attribute	Value
Machine Name	500x500mm Welded Steel Square Tube Mill By GI Steel Coil
Product	Square tube
Feature	Precision
Material	Carbon steel and galvanized steel
Max Size	500x500mm
Thickness	3mm
Length	6-12m
Rollers	Not included
Model	500x500

Product Description

The 500x500mm Welded Steel Square Tube Mill by GI Steel Coil is engineered to produce high-quality square pipes with dimensions up to 500x500mm and thickness ranging from 1-3mm. Utilizing advanced roll pass design, this production line ensures superior machining quality and high-precision assembly.

Design Features

Designed with operational efficiency and safety in mind, this square tube mill incorporates a double-radius hole style design to enhance performance while reducing roller costs. The system guarantees high production efficiency and consistent output quality.

Technical Specifications

Material Specifications:

Standard: International standard tube mill machine
Material: Galvanized steel
Mechanical properties: σb≤520Mpa, σs≤365MPa
Strip Width: 1000-2000mm
Strip Thickness: 6-12mm
Inner Diameter of Coils: Φ508mm
Outer Diameter of Coils: Φ1300～φ2000mm
Coil Weight: ≤25T

Pipe Specification:

Pipe Diameter: Round pipe 300x300-500x500mm
Length: 3-6m
Pipe-cutting Precision: 0-6mm
Forming Speed: Max 40m/min for 10mm thickness

Customer-Supplied Requirements

Workshop: 100x12m, H＞5m (crane to ground)
Power: Approx. 3500KW 380V/60Hz/3phases
Circulation Cooling Water (whole system): Flow:30+30 CBM, Pool Volume:40m³
Compressed Air (whole system): Flow:5m³/min, Pressure: 5-7kg/cm²
Cable: All cable outside of machine to be purchased after machine installation

Tube Mill Machine Working Process

Strip steel to coil → uncoiler → end straightener → flattener → shear welder → storage material unit → formed, welding, cooling, accurate pipe diameter size → accurate pipe length size, cutting → inspection → package
