Product Details:
Payment & Shipping Terms:
|
Product Name: | High Productivity Steel Pipe Product Line For Square Or Round Pipes | Key Words: | High Productivity Steel Pipe Product Line |
---|---|---|---|
Pipe Length: | 6m-12m | Pipe Width: | 45mm-114mm |
Pipe Thickness: | 1.5mm-5.0mmm | Forming Speed: | 30-60m/min |
Power: | 300KW | Main Section Capacity: | 400KW |
Dimension: | 100m*16m*2m | Usage: | Pipe Makimg |
High Light: | Round Steel Pipe Product Line,Square Steel Pipe Product Line,High Productivity Steel Pipe Product Line |
Production Description
The Steel Pipe Production Line is an automatic tube making machine designed to produce high-quality galvanized steel tubes in a short period of time. It is equipped with a 400kw power supply and a 300KW frequency converter to ensure a high production speed. The maximum pipe thickness it can produce is 1.5-5.0mm. It is suitable for a wide range of industries, including construction, automotive, furniture, and even oil fields. The steel pipe production line is simple to operate, reliabl e, and energy-efficient. It also has an adjustable tension system, which provides a consistent and reliable product. With a long service life and a low operating cost, our steel pipe production line provides an economical solution for all of your tube making needs.
Technical Parameters:
Product Name: | High Productivity Steel Pipe Product Line for Square or Round Pipes |
Voltage | 380V/50Hz/3Phase |
Welding Power | 300KW |
Welding Method | High Frequency |
Type | Square tube mill |
Cooling System | Water Cooling |
Tolerance | ±0.02mm |
Applications:
High Productivity Steel Pipe Product Line for Square or Round Pipes
Brand Name:TENGTIAN
Model Number:HG114
Material:Steel
Pipe Thickness:1.5mm-5.0mm
Warranty:1 year
Production Speed:30-60m/min
The TENGTIAN High Productivity Steel Pipe Product Line is a complete set of pipe production equipment, designed for producing welded steel tubes. It is widely used in oil and gas, water supply and drainage, agriculture, automotive, furniture, and other industries. This production line is composed of tube mill, high-frequency welding machine, galvanized steel tube mill, and other parts. The material of the steel pipe is steel, and the tube thickness is 1.5mm-5.0mm. The production speed is high, and it is very efficient in production. This product comes with a 1-year warranty and is guaranteed to provide quality production.
Customization:
We provide customized services for Square Tubular Mill, Square Tubing Rolling Mill, and Square Tubular Mill Line. Our products are branded as TENGTIAN with model number 200X200. They are made in China with speed of 30-60m/min, thickness of 1.5mm-5.0mm, horizontal accumulator, length of 6-12m, and material of steel.
Working Process
Coil Car→Uncoiler→Pinching and Leveing→Shearing and Butt-welding→Loop Storage→Edge Moving→Forming→Welding→IF Annealing→Water Cooling→Online NDT Treating→Sizing→Cutting→Straightening→End-facing and beveling→Hydrostaic Testing→Product Inspection→Weight and Measuring→Painting and Marking→Storage→Packing
1) We will send the engineer for the installation and training your workers how to operate this machine in correct way.
2) Warranty Team
One year quality guarantee, life guarantee repair. Within quality guarantee period, except for failures caused by human error, repair parts will be provided for free. After the quality guarantee period, only charge the cost of the spare parts.
3) We supply the pre-sell and after-sell service.
Pre-sell service: workshop design, and production output design
After-sell service: installation and training, and the skilled engineer for working.
4) We can also send the engineer working for you several months or 1 year. The engineer will help you to improve the output, reduce the waste and decrease the cost.
5) We supply the pre-sell service Design for whole project for stainless steel pipe making/ carbon steel pipe making.
6) We will be responsible for the loading and shipping.
Packing and Shipping:
High Productivity Steel Pipe Product Line for Square or Round Pipes is packaged and shipped in secure, weatherproof containers. The containers are designed to protect the product from shock, vibration, and moisture during transportation. Special packing materials are used to ensure the product is safe during shipping. The product is shipped with an inspection certificate, which includes the name and signature of the responsible inspector.
Equipment arriving at the buyer, the technical services personnel at the scene debugging, maintenance, equipment commissioning, commissioning, operation and maintenance instruction, responsible for technical training for equipment operation and maintenance personnel of the buyer. Used in users abide by the rules, under normal operating equipment, since 12 months from the date of the arrival of the equipment, such as positively impact on the quality to use, parts damage lead to equipment can't normal work, factory will give the repair or replacement free of charge.
