Fully Automatic Steel Pipe Production Line 12-63mm API Standard

Name: Fully Automatic Steel Pipe Production Line 12-63mm API Standard
Brand: Hebei Tengtian Welded Pipe Equipment Manufacturing Co.,Ltd.
SKU: HG 76
Price: 50,000.00 USD
Availability: InStock

Product Details:

Place of Origin:	Shijiazhuang China
Brand Name:	Tengtian
Certification:	CE,ISO9001, BV
Model Number:	HG 76

Detail Information

Place of Origin:

Shijiazhuang China

Brand Name:

Tengtian

Certification:

CE,ISO9001, BV

Model Number:

HG 76

Raw Material:

Carbon Steel, Galvanized Steel

Coil Weight:

6 Ton

Production Length:

3-12m

Main Section Capacity:

400KW

Automation:

Fully Automatic

Cutting Method:

Cold Saw Cutting

Type Of Welding:

High Frequency Welding

Welding Speed:

Max 70m/min

Application:

Pipe Production Under API Standard

Prodution Capability:

20-100m/min

Key Words:

Adjustable Large Pipe Size

Highlight:

High Light

Highlight:

120m/min Steel Pipe Production Line

Customizable Steel Pipe Production Line

Max Speed Steel Pipe Production Line

Trading Information

Minimum Order Quantity:

1 Set

Price:

$100000 to $1 million

Packaging Details:

Standard Export Packing

Delivery Time:

90 days

Payment Terms:

L/C,T/T

Supply Ability:

50 Sets/Yearly

Product Description

Customizable Steel Pipe Production Line with Max Speed 120m/min

Product Specifications

Attribute	Value
Raw Material	Carbon Steel, galvanized steel
Coil Weight	6 Ton
Production Length	3-12m
Main Section Capacity	400KW
Automation	Fully Automatic
Cutting Method	Cold Saw Cutting
Type Of Welding	High Frequency welding
Welding Speed	Max 70m/min
Application	Pipe production under API standard
Production Capability	20-100m/min

Product Description

HG50 High-Frequency Welded Pipe Mill Line is designed to produce welded pipes of Ф12～63mm in diameter and 0.5～2.0mm in wall thickness as well as square and rectangular pipes and deformed pipes of the corresponding size. Adopting roll pass design, the production line can manufacture welded steel pipes with good quality machining and high precision assembling.

Available Models

Serial number	Model	Thickness(mm)	Specification(mm)	Speed(m/min)	Main engine(kw)	Power(kw)	Area
1	H20	0.3-1	8-20	30-120	55	60	7*50
2	H32	0.3-2.0	12-32	30-120	75	100	7*50
3	H50	0.8-2.5	16-50	30-110	110	150	7*60
4	H60	0.8-3	20-60	30-100	132	200	7*65
5	H76	1-3	12-76	30-100	320	250	8*80
6	H89	1-4	32-89	30-80	350	300	8*80
7	HG114	1.5-5	45-114	30-60	400	300	10*100
8	HG165	3-7	60-165	30-50	600	400	10*110
9	HG219	4-8	114-219	20-40	800	500	12*150
10	HG273	4-10	114-273	15-30	1000	600	18*160
11	HG325	4-12	165-325	10-30	1200	600	18*180
12	HG426	4-16	165-426	8-25	1400	800	18*180
13	HG508	4-20	219-508	8-20	2000	1000	21*180

Production Process

Loading car
Uncoil
Cutting and Welding
Accumulator
Forming, HF welding, anneal welder, Deburring, Cooling, Sizing, Straightening
STD Cold-cutting saw
Transmitting
Hydrostatic testing
End facer
Straightener
Packing
Storage

About Our Company

The company has a strong technical ability, strong business ability, and vibrant team. Through the unremitting efforts of all staff, in recent years the company has occupied most of the domestic market, and exported to Korea, Vietnam, Indonesia, South Africa, Kazakhstan and other dozens of countries and regions.

Our Certifications

Our Services

We will send an engineer for installation and to train your workers in proper machine operation
One year quality guarantee with lifetime repair service
Comprehensive pre-sale and after-sale services including workshop design and production output design
Option to have our engineer work with you for several months to improve output and reduce costs
Complete project design service for stainless steel/carbon steel pipe making
Full responsibility for loading and shipping

Our Equipment

Global Presence

Our company specializes in the production of pipe mills, slitting lines, cold roll forming, stainless steel pipe mills and other equipment. Based on advanced Japanese technology, our machines are manufactured to Japanese standards with advanced configuration, stable quality, and excellent performance.

Exhibition Highlights

Shipping & Logistics

Our equipment has been exported to dozens of countries and regions including Egypt, Greece, South Korea, Vietnam, Indonesia, and South Africa, receiving favorable feedback from customers worldwide.
