Steel Pipe Manufacturing Machine 1-5mm Thickness
Product Specifications
| Attribute | Value |
|---|
| Product Name | CE Certification Steel Pipe Manufacturing Machine Automatic Line |
| Thickness Range | 1.0 - 5.0mm |
| After sales service | Engineers available to service overseas |
| Cutting Speed | 0-100m/min |
| Material | HRC; CRC; GI; COLOR STEEL |
Product Description
The CE Certification Steel Pipe Manufacturing Machine Automatic Line is designed to uncoil and level coil strips, then shear them to specified lengths at speeds up to 100m/min. This high-performance cut-to-length (CTL) machine is ideal for processing thin sheets or coils with precision and efficiency.
System Components
The ISO9001 certified system includes: coil loading car, single-mandrel decoiler, coil-head guide, press & shoveling equipment, pinch-feeding roller & leveling machine, hole accumulator, side guide, fine leveling & length-fixing machine, pneumatically mechanical shearing machine, delivery belt, piling-up bracket, up-down lifting table, moving-out car, hydraulic system and electric control system.
Technical Capabilities
The high-speed CTL machine processes steel coils with thickness ranging from 0.2-5mm, with customizable width and length specifications to meet customer requirements.
Key Features and Advantages
- Fast speed and high precision: Operating at up to 100m/min (25-30pcs/min for 2000mm sheets). Precision levels: ±1mm/m² for leveling, ±0.5mm/m for sheet length, ±0.5mm/m for diagonal length.
- Optimized uncoiling: Single mandrel (cantilever) uncoiler design for efficient processing of lighter coils.
- Precision leveling: Scientifically calculated leveling roller diameters ensure perfectly flat steel sheets.
- Automated stacking: Integrated piling-up bracket organizes finished sheets automatically.
- Surface protection: Hole accumulator between leveling stages safeguards sheet quality while maintaining synchronization.
Model Specifications
| No. | Model | Pipe Size | Thickness | Speed (m/min) | Capacity (KW) | HF (KW) | Area (LxW in Metres) |
|---|
| 1 | HG20 | ø8 - ø20 mm | 0.3 - 1.5 mm | 30 - 150 | 210 | 100 | 40*12 |
| 2 | HG32 | ø10 - ø32 mm | 0.4 - 2.0 mm | 30 - 150 | 300 | 150 | 40*12 |
| 3 | HG50 | ø16 - ø50 mm | 0.7 -2.5 mm | 30 - 150 | 410 | 200 | 60*12 |
| 4 | HG60 | ø22 - ø60 mm | 0.9 - 3.0 mm | 30 - 150 | 410 | 200 | 60*12 |
| 5 | HG76 | Ø25 - ø76 mm | 1 - 4 mm | 30 - 120 | 580 | 300 | 80*16 |
| 6 | HG89 | Ø32 - ø89 mm | 1 - 4.5 mm | 30 - 100 | 660 | 300 | 100*16 |
| 7 | HG114 | Ø45 - ø114 mm | 1.5 -5 mm | 30 - 80 | 920 | 400 | 100*16 |
| 8 | HG140 | Ø50 - ø140 mm | 1.5 - 5.5 mm | 30 - 80 | 920 | 400 | 100*16 |
| 9 | HG165 | Ø60 - ø165 mm | 2 - 6 mm | 30 - 60 | 1100 | 500 | 100*16 |
| 10 | HG219 | Ø114 - ø219mm | 3 - 8 mm | 20 - 45 | 1400 | 600 | 150*16 |
| 11 | HG273 | Ø114 - ø273mm | 4 - 12 mm | 15 - 30 | 2100 | 800 | 160*18 |
| 12 | HG325 | Ø165 - ø325 mm | 4 - 14 mm | 10 - 30 | 2500 | 1000 | 200*24 |
| 13 | HG426 | Ø165 - ø426 mm | 4 - 16 mm | 8 - 25 | 2900 | 1200 | 250*24 |
| 14 | HG508 | Ø219 - ø508 mm | 5 - 18 mm | 5 - 18 | 3400 | 1600 | 300*24 |
| 15 | HG610 | Ø355 - ø610 mm | 5 - 18 mm | 5 - 18 | 3700 | 1600 | 300*24 |
| 16 | HG760 | Ø426 - ø760 mm | 5 - 20 mm | 5 - 20 | 4300 | 1800 | 300*24 |
1.) We will send the engineer for the installation and training your workers how to operate this machine in correct way.
2.) Warranty Team
One year quality guarantee, life guarantee repair. Within quality guarantee period, except for failures caused by human error, repair parts will be provided for free. After the quality guarantee period, only charge the cost of the spare parts.
3.) We supply the pre-sell and after-sell service.
pre-sell service: workshop design, and production output design
after-sell service: installation and training, and the skilled engineer for working.
4.) We can also sent the engineer working for you serval months or 1 year. The engineer will help you to improve the output, reduce the waste and decrease the cost.
5.) We supply the pre-sell service-Design for whole project for stainless steel pipe making/ carbon steel pipe making.
6.) We will be responsible for the loading and shipping
Q1: Are you manufacturer or trading company?
A1: we are manufactuer , more than 20 years experience.
Q2: What is the max size of pipe you have even produce?
A2: Max φ630mm
Q3:Can I visit your customer machine line?
A3: Yes, but I need to get agreement from my customer firslty.
Q4: what is your machine advantages?
A4:Contain Full automatic, Direct forming square, Share rollers. Fast change system
Q5:How I can get the quotation?
A5:Please send your requires of pipe size , thickness to us.
