High Precision Tube Mill Machine 25.4-76.2mm Dia. 100m/min Speed
High Precision Tube Mill Machine 25.4-76.2mm Dia. 100m/min Speed
  • High Precision Tube Mill Machine 25.4-76.2mm Dia. 100m/min Speed
  • High Precision Tube Mill Machine 25.4-76.2mm Dia. 100m/min Speed

High Precision Tube Mill Machine 25.4-76.2mm Dia. 100m/min Speed

Product Details:
Place of Origin: Hebei
Brand Name: Teng Tian
Certification: CE / ISO9001:2008/ BV
Model Number: HG76
Detail Information
Place of Origin:
Hebei
Brand Name:
Teng Tian
Certification:
CE / ISO9001:2008/ BV
Model Number:
HG76
Pipe Dia. Tolerance:
±0.03mm
Line Speed:
Max.100m/min
Forming Method:
Cold Roll Forming By Rollers
Welding Type:
High Ferquency Welding
Cutting:
Cold Saw; Without Burr
Feature:
High Precision; More Stable; High Speed;
Customized:
Machine Designing As Per Customer Requirement
Diameter Range:
25.4 - 76.2mm
Thickness Range:
1.0-4.0mm
Colour:
Blue
Name:
Tube Mill Machine
Highlight:

High Light

Highlight:

carbon steel tube mill

,

tube making machine

Trading Information
Minimum Order Quantity:
1 Set
Price:
$100000 to $1 million
Packaging Details:
Special export packing, and fixed in container
Delivery Time:
2.5 Months
Payment Terms:
T/T,L/C
Supply Ability:
100 Sets / Year
Product Description
Stable Blue Tube Mill Machine Cold Roll Forming With Stable Condition
Product Specifications
Attribute Value
Pipe Dia. Tolerance ±0.03mm
Line Speed Max.100m/min
Forming Method Cold Roll Forming by Rollers
Welding Type High Frequency Welding
Cutting Cold Saw; Without Burr
Feature High Precision; More Stable; High Speed
Customized Machine Designing As Per Customer Requirement
Diameter Range 25.4 - 76.2mm
Thickness Range 1.0-4.0mm
Colour Blue
High Precision High Speed Tube Mill Machine

Designed to produce welded pipes in diameter range of 25.4mm - 76.2mm with wall thickness of 1.0mm - 4.0mm, as well as corresponding square and rectangular pipes. Ideal for applications in metallurgy, construction, transportation, machinery and vehicle industries.

Production Process
  • Scroll up
  • Uncoil
  • Flattening
  • End Shear & Butt Welding
  • Accumulator
  • Forming
  • High-frequency induction welding
  • Removing external burr
  • Cooling
  • Sizing
  • Cutting
  • Checking & Collecting
  • Accessing Warehouse
Technical Specifications
1. Raw Material:
Material application HRC, CRC, galvanized steel strips
Material grade Low-carbon steel, low alloy steel: δs≤235Mpa
ID of the steel strips Φ450-Φ508mm
OD of the steel strips Φ800-Φ1800mm
Coiler weight Max.4000kg
2. Production Range:
Pipe Type Size Range Thickness
Round Pipe 25.4 - 76.2mm 1.0-4.0mm
Square Pipe 20*20 - 60*60mm 1.0-3.0mm
Rectangular Pipe 15*25 - 80*40mm 1.0-3.0mm
3. H.F. Welder: GGP300Kw Solid State
4. Line Speed: Max.100m/min
5. Tube Length: 4-12m
6. Pipe Dia. Accuracy: ±0.03mm
7. Cutting Accuracy: ±3mm
8. Installation Capacity: 600kw

As a CE & ISO9001:2008 certified pipe making machine manufacturer and supplier in China, our machines are exported to over 40 countries including Turkey, Egypt, Morocco, Kazakhstan, and Mexico. Our products are known for their high quality, reliable performance and long service life.

High Precision Tube Mill Machine 25.4-76.2mm Dia. 100m/min Speed 0

For more information about our tube mill machines, please contact us. We're happy to assist you with your requirements.
