Welded Steel Pipe100m/Min 300w Square Pipe Manufacturing Machine

Large Image : Welded Steel Pipe100m/Min 300w Square Pipe Manufacturing Machine

Product Details:

Place of Origin:	HEBEI，CHINA
Brand Name:	TENGTIAN
Certification:	CE/ISO9001/BV
Model Number:	HG32

Payment & Shipping Terms:

Minimum Order Quantity:	1SET
Price:	$100000 to $1 million
Packaging Details:	Seaworthy packing
Delivery Time:	3 months
Payment Terms:	L/C, T/T, Western Union
Supply Ability:	150 units one year

Contact Now

Detailed Product Description

Product Name:	Welded Steel Pipe100m/Min 300w Square Pipe Manufacturing Machine	Pipe Material:	Carbon Steel
Voltage:	380V/220V	Weight:	About 12 Tons
Pipe Shape:	Round,square	Pipe Diameter:	10-32mm
Thickness:	0.4-1.5mm	Speed:	30-100m/min
Power(w):	300w	Keywords:	Square Pipe Manufacturing Machine
Highlight:	100m/min square pipe manufacturing machine , 300w square pipe manufacturing machine , 100m/min square tube manufacturing machine



The H32 steel square pipe making machine is intended for manufacturing of round pipe ofΦ10mm-Φ32mm with thickness of0.4mm–1.5mm from cold-rolled and hot-rolled coil strip by means of unclosed tubular blank with its subsequent welding into tube, edge heating by means of solid state high-frequency welder, longitudinal seam welding in rolls of tube welding machine, cooling, further sizing or shaping and on-stream cutting of endless tube in measured lengths.
Finished product will be of round, square or rectangular pipe.
We also can manufacture H32 H60 H127 steel square pipe making machine.

What is the Features of steel square pipe making machine?

1.It supports many kinds of material like carbon steel, GI and others.

2.One steel square pipe making machine could make a large range of pipe sizes by changing mold.

3.One steel square pipe making machine could be used to make square pipe, round pipe by changing mold.

4.The pipe made by this kind of steel square pipe making machine could be used in many areas like water tube, wire pipe and others

What is the working flow of steel square pipe making machine?

Steel Tape→→ Double-head uncoiler →→Strip-head Cutter and welder→→Spiral accumulator→→Forming section(Flattening unit +Main driving unit +Forming unit +Guide unit +High frequency induction welding unit +squeeze roller)+Removing External and internal burr→→Cooling unit →→ Sizing unit and straightener →→Flying saw under computer-control →→ Run-out table

Specification

Model	Diameter(mm)	Thickness(mm)	Speed(m/min)	Main power(kw)	HF welder(KW)	Area(m2)
HG32	10-32	0.4-1.5	30-100	250	100	12x100
HG50	12-50	0.6-2.5	30-90	300	150	12x100
HG76	12-76	1-3	30-90	320	200	12x100
HG89	32-89	1-4	30-80	350	300	12x100
HG114	45-114	1.5-5.0	30-60	400	300	12x100
HG165	60-165	3-7	30-50	600	400	12x100
HG219	114-219	4-8	20-40	800	500	15x150
HG273	114-273	4-10	15-30	1000	600	18x160
HG325	165-325	4-10	10-30	1200	600	12x100
HG426	165-426	4-12.7	8-25	1400	800	12x100
HG508	219-508	4-16	8-20	2000	1000	12x100
