Full Automatic Pipe Making Machine 10-50mm Diameter 90m/min
Full Automatic Pipe Making Machine 10-50mm Diameter 90m/min
  • Full Automatic Pipe Making Machine 10-50mm Diameter 90m/min
  • Full Automatic Pipe Making Machine 10-50mm Diameter 90m/min
  • Full Automatic Pipe Making Machine 10-50mm Diameter 90m/min

Full Automatic Pipe Making Machine 10-50mm Diameter 90m/min

Product Details:
Place of Origin: HEBEI,CHINA
Brand Name: Tengtian
Certification: CE ISO
Model Number: HG50
Detail Information
Place of Origin:
HEBEI,CHINA
Brand Name:
Tengtian
Certification:
CE ISO
Model Number:
HG50
Product Name:
Full Automatic Pipe Making Machine Milling Cold Saw Flexible Adjustment
Pipe Diameter:
10-50mm
Product Speed:
Max 90m/min
Material:
Steel Pipe,stainless Pipe
Special Require:
Can Design According To The Customer
Keyword:
Full Automatic Pipe Making Machine
Highlight:

High Light

Highlight:

tube milling machine

,

steel pipe making machine

,

steel pipe manufacturing machine

Trading Information
Minimum Order Quantity:
1 set
Price:
$100000 to $1 million
Packaging Details:
packed in seaworthy material
Delivery Time:
2 months
Payment Terms:
L/C,T/T,Western Union
Supply Ability:
200 set per year
Product Description
Full Automatic Pipe Making Machine Milling Cold Saw Flexible Adjustment
Product Specifications
Attribute Value
Pipe Diameter 10-50mm
Product Speed Max 90m/min
Material Compatibility Steel pipe, stainless pipe
Customization Can be designed according to customer requirements
Technical Parameters
  • Material: HRC, CRC
  • Motor Type: Servo Motor
  • Cutting Speed: Max 30m/min
  • Warranty: 1 Year
  • Round Pipe Size: 400x400mm
  • Thickness: 10.0-16.0mm
  • Cutting Accuracy: ≤±2mm
  • Square Pipe Size: 200*200 - 400*400mm
540 Computer Flying Saw Parameters
  • Cutting Length: 0.5-32m tunable
  • Cutting Precision: ±3mm
  • Max Cutting Frequency: 10 cuttings per min
  • Max Speed: 50m/min
  • Max Thickness of Pipes: 16mm
  • Saw Head Action: Hydraulic Drive (Flat-pushing Manipulation)
  • Pipe Clamp: Hydraulic Clamping
Cold Cutting Saw Features
  • Automated sawing tubes inline/offline with high production
  • High Speed Steel or Carbide Tipped Blades
  • YASKAWA/SIEMENS servo motor & premium brand electric components
  • Compatible with various tube profiles
  • Eliminates secondary chamfering or de-burring
  • Works with Carbon Steels, Stainless Steels, HSLA
  • High speed and precision cutting with excellent edge quality
Buyer Requirements
  • Workshop: 70x8m, H＞5m (crane to ground)
  • Power: Approx.500KW 380V/50Hz/3phases
  • Circulation Cooling Water: Flow:20T/h～30 T/h, Pool Volume:30m³
  • Compressed Air: Flow:5m³/min, Pressure: 5-7kg/cm²
  • Cable: All cables outside of machine to be supplied by buyer
Note: The data in the form is for reference according to general ranges. We design and manufacture each line according to specific customer requirements, ensuring each customer receives a customized Cold Saw solution.
Our Services
Engineer dispatch for installation and operator training
One year quality guarantee with lifetime repair support
Pre-sale services including workshop and production output design
After-sale services including installation, training, and technical support
Option for extended engineer support (months to 1 year) for production optimization
Complete project design for stainless/carbon steel pipe production
Responsible for loading and shipping arrangements
